📝 Wiring help needed.
Thanks Doug, I have sketched the layout as best I can.
Lights and radar will be switched direct to batteries
I need 4 channels to operate the esc, rudder, fire hydrant
rotation, and fire hydrant
The pump is switched via micro switches and cam on the rotator so it only works when pointing away from the boat.
What I need to do is to get the thruster to run in 2 directions???
The UBEC can give me either 5 or 6 volts output. So I'll need to switch it somehow, as it only needs to run at one speed.
I only have a 4 channel rc transmitter
and receiver spare at present, so I may go with a fixed height on the fire hydrant
if i need another servo channel to control the thruster. 🤔
ALL and any help gratefully received.
Now to go and look at the electrics on the Wavemaster.
