    CB90
    Lieutenant Commander
    ๐Ÿ“ Watercat M12 Nautical Marine Models
    Flag
    Country: ๐Ÿ‡ฌ๐Ÿ‡ง United Kingdom
    Online: 21 hours ago
    ๐Ÿ˜Š View Profile
    ๐Ÿ’ฌ Send PM
    Extra pics to help build .
    note stern has a rounded edge, missed on most builds.
    Regards Roy
    CB90
    Lieutenant Commander
    ๐Ÿ“ Watercat M12 Nautical Marine Models
    Flag
    Country: ๐Ÿ‡ฌ๐Ÿ‡ง United Kingdom
    Online: 21 hours ago
    ๐Ÿ˜Š View Profile
    ๐Ÿ’ฌ Send PM
    Found this on the net, I hope it may be of use, I will use to try to build a new scratch build, unfortunately there is not a stern or bow view!
    regards Roy
    Regards Roy
    CB90
    Lieutenant Commander
    ๐Ÿ“ Watercat M12 Nautical Marine Models
    Flag
    Country: ๐Ÿ‡ฌ๐Ÿ‡ง United Kingdom
    Online: 21 hours ago
    ๐Ÿ˜Š View Profile
    ๐Ÿ’ฌ Send PM
    Watercat M12 seems to have disappeared there is a article on the model boats magazine web site

    http://www.modelboats.co.uk/news/article/watercat-m12--u619/...

    The model is kitted to a scale of 1:16 which gives a model hull length of 35 inches and 10 inches beam. The kit includes a GRP hull,

    In the late 1990s, the Finnish Navy began to modernise the mobility and equipment of coastal defence forces. Marine Alutech Oy Ab designed and developed the WATERCAT M12, a new type of a troop carrier for the Finnish Marines for landing and transportation purposes in all weather conditions.

    The water jet system gives the boat excellent manoeuvrability and can stop almost within one boatโ€™s length from full ahead. An essential advantage in coastal use is that the bottom of the boat is perfectly smooth, enabling the boat to operate in very shallow waters safely.

    There are 20 damped seats with seat belts on the fore deck and the deck is sheltered with a light composite cover. Hatches on the cover and a hydraulically operated bow ramp ensure fast unloading and loading of cargo and personnel.

    The equipment includes the latest marine electronics and communications systems. Low noise level (under 75 dBA) and ergonomically placed instruments help the skipper to handle and operate the boat safely and comfortably despite rugged military use. For military and patrol purposes the boat can be equipped with two 12.7 mm machine guns.

    General characteristics
    LOA14,25 M
    LENGTH13,10 M
    BEAM3,65 M
    DRAFT0,70 M
    WEIGHT10,3 TON
    DISPLACEMENT13,8 TON
    SPEED (MAX)>35 KN
    SPEED (CRUSING)>30 KN
    RANGE>180 NM
    http://www.modelboats.co.uk/news/article/watercat-m12--u619/14635
    ๐Ÿ”—
    Regards Roy
    Northernflotsam
    Master Seaman
    ๐Ÿ“ Watercat M12 Nautical Marine Models
    Flag
    Country: ๐Ÿ‡ฌ๐Ÿ‡ง United Kingdom
    Online: 3 months ago
    ๐Ÿ˜Š View Profile
    ๐Ÿ’ฌ Send PM
    Any one any idea if anyone took over the watercat m12 U619 kit ? by Nautical Marine Models .

    or anyone have the drawings for it ? or where I could even find those ...
