Bad Ass and Green Streak airboat's
5 Photos · 8 Likes · 3 Comments
Boat Length
10" (25.4 cm)
Boat Weight
0.5kg (18 oz)
Motor Type
Brushless
Drive Type
Direct
Props
Single
Max Amps
40A
Battery Type
LiPo
Battery mAh
1Ah (1,000 mAh)
Prop Type
3 Blade
Prop Size
140mm
Run Time
10 min
Model Speed
15mph (24kph)
28 days ago by 🇬🇧 HappyHaggis
2 but shortly will be 20 rc airboats. I found a free stl file for a 3d printed airboat and got to work altering it with an inbuilt air tight section in the bow and a better laid out hull along with clean wire free motor and rudder installation. Everything is serviceable and removes with a couple of screws.They have a small gyro to help them track better and are powered by 1800kv motor, 40amp esc and a 2s 1000 30c lipo.
Rubber bumper strip and the option for FPV camera
These are for a new low cost racing league for our club this year.
I say low cost as its £2.19 to print each boat. 87p for esc, £1.10 for servo, £6 motor, £7 propeller, £10 lipo! So £27.16 if you have you're own transmitter and receiver.
The optional gyro can be found for as little as £5 though i increased the depth of the strakes on the flat hull to help them track better
▲
⟩⟩
ChrisF
BOATSHED
jumpugly
GaryLC
Willem
ColinJ2
EdW
hermank
|
💬 Re: Bad Ass and Green Streak airboat's
23 days ago by 🇬🇧 BOATSHED (
 Commander)✧ 15 Views · 1 Like
Flag
I love you little Air Boat.m It reminds me of way back in the 60's and 70's when you could buy the wooden ones to mount an I/C engine on them.
But those where never able to have R/C in them. I would love one like yours but twice the length and maybe half as wide. I amase at you people who 3d print things. Like the Massive Bluebird Model that has been done. I was surprised that yours carried on and came back to shore under it's own power upsied down. Amazing. 👍👍 ▲
⟩⟩
hermank
|
|
Login To
Remove Ads 💬 Re: Bad Ass and Green Streak airboat's
28 days ago by 🇬🇧 HappyHaggis (
 Sub-Lieutenant)✧ 36 Views · 1 Like
Flag
Hi Willem yes they are on Printables. A few weeks tweaks here and there and they come out well. Not sure why they aren't more popular
▲
⟩⟩
hermank
|
|
💬 Re: Bad Ass and Green Streak airboat's
28 days ago by 🇩🇪 Willem (
 Petty Officer 1st Class)✧ 38 Views · 2 Likes
Flag
These look great fun. Can you give the location of the stl files?
▲
⟩⟩
