IRON EXECUTIONER
4 Photos · 14 Likes · 8 Comments
Boat Length
44" (111.76 cm)
Boat Weight
3.5kg (123 oz)
Motor Type
Brushed
Drive Type
Direct
Props
Twin
Max Amps
50A
Battery Type
LiPo
Battery mAh
3Ah (3,000 mAh)
Prop Type
6 Blade
Prop Size
30mm
Run Time
30 min
21 days ago by 🇬🇧 HappyHaggis
A new design and at just over 1 metre and 45cm tall she's a fairly good sized vessel. Twin motor with a gyro to help her track. Twin working stabiliser fins, bow thruster, spinning radar, ballast tank in the bow.Twin 545 brushed motors with 2 x 80amp esc spinning 2 x 30mm 6 blade props
Last photo is Ai of what I'm aiming for as an end result
▲
⟩⟩
EdW
DuncanP
GARTH
SimpleSailor
RogerA1
IGinBasel
Rookysailor
jumpugly
Ronald
Mike Stoney
Northernflotsam
hermank
chugalone100
Wolle
|
💬 Re: IRON EXECUTIONER
2 hours ago by 🇬🇧 HappyHaggis (
 Sub-Lieutenant)✧ 3 Views · 0 Likes
Flag
A few more cosmetic bits done now. Still awaiting the RC helicopter arriving for the helipad and awaiting new filament to print the spinning radar. Have an extra water pump onboard now so that's 4 speed controllers now along with 3 batteries. In yesterday's bath test at 5% throttle which gives a slow Ish cruise speed she sat running for 5 hours and 15min and I had 22% left until low voltage cut off out of the twin 3s 5200mah 80c lipo batteries and both motors where Luke warm
Gyro has been adjusted again on the stabiliser fin so the next non gale force wind day will get back to the river for more sea trial's.
▲
⟩⟩
No likes yet
This member will receive 1 point for every like received |
|
Login To
Remove Ads 💬 Re: IRON EXECUTIONER
11 days ago by 🇬🇧 HappyHaggis (
Sub-Lieutenant)✧ 19 Views · 2 Likes
Flag
More progress and getting closer to pond trials. Still aiming for this Sunday morning. Tomorrow the premium ballraced propshafts will be fitted along with her 5 bladed 40mm props. Some mixing to do in the bath tomorrow evening to get the steering and fwd/rwd finely tuned. The rest of the detailed painting will happen after the pond trials.
Battery arrived in the form of a 3s 5200mah 80c though the motors will be limited to 30% power available. Estimated constant run time of around 1 hour Rc helicopter has been ordered for the helipad
▲
⟩⟩
chugalone100
hermank
|
|
💬 Re: IRON EXECUTIONER
20 days ago by 🇬🇧 HappyHaggis (
Sub-Lieutenant)✧ 34 Views · 7 Likes
Flag
Hi Pete
Yes and very easily. The recommended build plate size would be 220mm and upwards. I've designed a couple of high pitch 3 blade propellers for her also that would be ample. They are 50mm and are left hand and right hand. I will be trying a 5 blade and 7 blade skewed propeller design too. I'm trying to get as much thrust from as low rpm as possible. These 3 blade propellers pull 14amp at a capped 50% throttle and in the bath on my test board they produce plenty of thrust. My scales reading is 700g of it Regards Scott
▲
⟩⟩
EdW
chugalone100
Rookysailor
Northernflotsam
Mike Stoney
SimpleSailor
hermank
|
|
💬 Re: IRON EXECUTIONER
20 days ago by 🇬🇧 Rookysailor (
 Rear Admiral)✧ 35 Views · 3 Likes
Flag
I have a Bambu Lab P2S printer, would that be able to print your craft.
Cheers, Pete 😊 ▲
⟩⟩
Mike Stoney
hermank
HappyHaggis
|
|
💬 Re: IRON EXECUTIONER
20 days ago by 🇬🇧 HappyHaggis (
Sub-Lieutenant)✧ 38 Views · 4 Likes
Flag
More sanding completed and some additional parts printed. Have decided to add further railings towards the stern area.
Now working on electronics for the spinning radar and moving spotlight, nav lights and spluttering exhaust cooling outlets
▲
⟩⟩
EdW
chugalone100
Mike Stoney
hermank
|
|
💬 Re: IRON EXECUTIONER
21 days ago by 🇬🇧 HappyHaggis (
Sub-Lieutenant)✧ 57 Views · 7 Likes
Flag
Hi its the Creality K2 Plus with 350mm x 350mm bed size and using PLA+. She's quite small in terms of what tou could print from that bed. Could easily use a smaller 220mm bed for this size.
Will be coated in Epoxy resin before a few layers of the gunmetal grey paint and lacquer. Also for the stl files. Once I've finalised a few errors in the print model I'll happily hand them out. The original real vessel is the Stan patrol vessel and it shares part of that design. Part of the bow is 1inch solid PLA for strength with a 2cm solid keel line as a backbone. I'm going to glass some internal joints for added peace of mind though the sections are coming together nicely. Heres a photo of the smaller accessories printer hard at work with guardrails, bollards, spot lights, rudders and A-frame
▲
⟩⟩
EdW
chugalone100
Northernflotsam
Mike Stoney
SimpleSailor
Rookysailor
hermank
|
|
💬 Re: IRON EXECUTIONER
21 days ago by 🇬🇧 Northernflotsam (
 Chief Petty Officer 2nd Class)✧ 77 Views · 2 Likes
Flag
How long did the printing take ? (what printer bed size) as thats a whopper 😊 What filament did you use ?
Looks a very nice hull. ▲
⟩⟩
HappyHaggis
hermank
|
|
💬 Re: IRON EXECUTIONER
21 days ago by 🇺🇸 Hhager2 (
Sub-Lieutenant)✧ 81 Views · 5 Likes
Flag
I’d that 3D printed? Where can I get files? Nice beginning. The stabilizer fins I like that. Had them on real Navy ship. It helped during a hurricane crossing the Atlantic. The one on left I had non working stab find. I have servos n could have made them like rudders or ailerons. I even have gyro board. Kick myself on not thinking of that.
▲
⟩⟩
