    Fairey Huntsman 31 (47โ€ SLEC kit) build blog
    by Skydive130 ๐Ÿ‡ฌ๐Ÿ‡ง ( Rear Admiral)
    ๐Ÿ“ฃ










    Click To
    Follow
    11 Posts 110 Comments 0 Photos 83 Likes
    Most recent posts shown first   (Show Oldest First) (Print Booklet)
    ๐Ÿ“ Small updateโ€ฆ.
    3 months ago by Skydive130 ( Rear Admiral)
    Flag
    View All
    Have had quite a bit on this past few days what with work, going up to Hull to see daughter and grandson, work and stuff around the house and garden to do, howeverโ€ฆ..

    Before going away I gave the outside of the hull another coat of Eze-Kote and the insides a sloshing of resin to seal everything up water tight.

    I then set about installing the motor, ESC, rudder servo and water pick up plumbing. All nice and tidy and all working in the correct direction ect..

    Today I did a bit more to the deck planking using photos from the interweb as reference and if Iโ€™m honest, using bass wood for the planks and mahogany strip for the caulking it looks quite effective after trimming and sanding. The stern planking has a little more to be done before I start up the sides leading to the bow where there will be quite a bit of work to get it right.

    Lastly, Iโ€™ve added a picture of the Bridlington Tamar class lifeboat from the weekend. Why? Because Iโ€™ve managed to get hold of a Model Slipway Tamar kit unstarted and that will be next on the building boardโ€ฆ..
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comments
    ๐Ÿ‘€ 58 Views
    9
    7
    ๐Ÿ’ฌ Re: Small updateโ€ฆ.
    1 month ago by Martin555 ( Fleet Admiral)
    Flag
    Hi Sy,
    Your Maggie M Trawler would of been a great build log to see, and also would help anyone else wanting to make it.

    Maybe you could slip in a mini build log for us.

    Just looking at the photos you have done a great job so far.

    Martin555.
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 20 Views
    ๐Ÿ’ฌ Re: Small updateโ€ฆ.
    1 month ago by Skydive130 ( Rear Admiral)
    Flag
    View All
    Hi Martin, no updates at the moment as Iโ€™m busy decorating and in the middle of a commission build of a model slipway Maggie M trawler. I was going to do a build blog on her, but as itโ€™s likely to take 6 months with everything else that is going on I didnโ€™t bother. Although I have done some updates on the โ€œmodels slipwayโ€ page on Facebook.

    Hope you are keeping well . Kindest regards simon
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 17 Views
    3
    ๐Ÿ’ฌ Re: Small updateโ€ฆ.
    1 month ago by Martin555 ( Fleet Admiral)
    Flag
    Hi Sy,

    Very nice work.
    Do you have any updates coming along soon ?

    Martin555.
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 22 Views
    1
    ๐Ÿ’ฌ Re: Small updateโ€ฆ.
    3 months ago by Skydive130 ( Rear Admiral)
    Flag
    Many thanks Mad, I think once all the planking and caulking is done and the mahogany strip around the decks perimeter, a couple of coats of varnish, it should look great!
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 56 Views
    1
    ๐Ÿ’ฌ Re: Small updateโ€ฆ.
    3 months ago by Skydive130 ( Rear Admiral)
    Flag
    Cheers Rick, I aim to please! Kind regards simon
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 56 Views
    1
    ๐Ÿ’ฌ Re: Small updateโ€ฆ.
    3 months ago by Madwelshman ( Warrant Officer)
    Flag
    Fair play, that looks spot on, what with that wood combination you have used and knowing what you are doing.
    It's going to be a cracker ๐Ÿ˜Ž๐Ÿ‘
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 53 Views
    2
    ๐Ÿ’ฌ Re: Small updateโ€ฆ.
    3 months ago by Newby7 ( Vice Admiral)
    Flag
    Again I say Sy you do neat work.๐Ÿ‘๐Ÿ‘๐Ÿ‘๐Ÿ‘๐Ÿ‘Well done.
    Rick
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 60 Views
    3
    ๐Ÿ“ Spray rails finished and other small tasksโ€ฆ.
    3 months ago by Skydive130 ( Rear Admiral)
    Flag
    View All
    This weekend has seen good progress, but thatโ€™s enough now as I have to fulfill husband dutiesโ€ฆ.

    I have finished the chine and spray rails following the same method as before, but found the second half a little quicker as Iโ€™d found a process that worked. Once all the rails were fitted, they were given a final sand to ensure that all curves were even and some very tiny amounts of filler where needed. Once all was good, any bare wood was given a further coat of Eze-Kote to seal them in.

    Question if I may? Will I be able to put a coat of finishing resin over the top of the Eze-Kote for a hard outer coat and possibly after wet n dry sanding, a better coat for painting without any undue reaction? Answers on a postcard tooโ€ฆ..

    I have made a brass water inlet pick up in a similar fashion to how Rob made his for his pilot boat. Not having a lathe I placed a brass nut on a screw into my drill bit, spun it up and filed it round and soldered it to the brass tube. I heated the brass tube prior to bending, cut it then soldered the brass nut on and epoxied the piece into the hull. Once set I soldered on a brass nut on the inside and a further coat of epoxy to confirm seal. The whole hull is due a coat of resin inside followed by silver paint, so all should be waterproof in the end.

    Last job was to confirm the propshaft was exactly inline with the motor coupling using my trusty solid coupling adaptor and also drilled a hole for the oiler.

    That will be it until Thursday when I shall getting all the sealing coats inside and out done, servo mount, rx mount, esc mount and other internal jobsโ€ฆ..
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comments
    ๐Ÿ‘€ 76 Views
    9
    13
    ๐Ÿ’ฌ Re: Spray rails finished and other small tasksโ€ฆ.
    3 months ago by ChrisF ( Chief Petty Officer 2nd Class)
    Flag
    Thanks Sy. I'd like to see at least one finished and on the water pretty soon out of the five builds I've got on the go!

    Chris
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 68 Views
    3
    ๐Ÿ’ฌ Re: Spray rails finished and other small tasksโ€ฆ.
    3 months ago by Skydive130 ( Rear Admiral)
    Flag
    Hi Chris,

    Such lovely boats, Fairey certainly built some classic lines! Yours look terrific, look forward to seeing them finished,

    Kind regards sy
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 68 Views
    2
    ๐Ÿ’ฌ Re: Spray rails finished and other small tasksโ€ฆ.
    3 months ago by ChrisF ( Chief Petty Officer 2nd Class)
    Flag
    View All
    Hi Sy

    I'd rather have the laser etched planking than nothing but agree that if one can do it planking gives the best effect.

    I've done it on three of my Fairey builds so far, photo shows my Huntsman 31 in the foreground and Swordsman behind.

    Unfortunately I haven't done any building for quite a few weeks now due to commitments and it being summer!

    Chris
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 68 Views
    5
    ๐Ÿ’ฌ Re: Spray rails finished and other small tasksโ€ฆ.
    3 months ago by Skydive130 ( Rear Admiral)
    Flag
    Hi Chris, the bow wasnโ€™t a pleasant task, but the result was pleasing so well worth the effort. As for size, I hear you, I think mine works out at 1:8 scale so almost action man scale and almost too big for my bench, never again ha ha!

    Kind regards Sy
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 74 Views
    2
    ๐Ÿ’ฌ Re: Spray rails finished and other small tasksโ€ฆ.
    3 months ago by Skydive130 ( Rear Admiral)
    Flag
    I hear your sentiments JB, the hobby is struggling to attract new builders, unfortunately todayโ€™s younger generation are probably more interested in playstations, fashion and many other things good and bad. We are sadly a dying breed ๐Ÿ˜ข
    Kind regards Sy
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 74 Views
    4
    ๐Ÿ’ฌ Re: Spray rails finished and other small tasksโ€ฆ.
    3 months ago by ChrisF ( Chief Petty Officer 2nd Class)
    Flag
    Nice to see another Huntsman 31 being built. You've made a very nice job of the flared bow, not easy.

    I did have a big Precedent version, bought already built, but found it too big for me and sold it on. Now scratch building one at 1:12 which matches my other Fairey builds.

    Chris
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 75 Views
    3
    ๐Ÿ’ฌ Re: Spray rails finished and other small tasksโ€ฆ.
    3 months ago by jbkiwi ( Fleet Admiral)
    Flag
    It would be a shame to lose you as well Colin, as there is a distinct lack of regular contributors at the moment, and that seems to be getting worse every month, to the detriment of the site. I hope things will come right soon before it goes too far, as we need experienced modellers to help the newcomers, or perhaps the hobby will die out completely.

    JB
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 76 Views
    4
    ๐Ÿ’ฌ Re: Spray rails finished and other small tasksโ€ฆ.
    3 months ago by Skydive130 ( Rear Admiral)
    Flag
    Cheers Colin, will be sorry to see you go if you leave, Martin sent me a private message yesterday saying heโ€™d left the site for the same reasons, all very sad ๐Ÿ˜ข

    Kind regards Sy
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 76 Views
    3
    ๐Ÿ’ฌ Re: Spray rails finished and other small tasksโ€ฆ.
    3 months ago by Colin H ( Vice Admiral)
    Flag
    Sy, you are welcome, chuck out any comments I make that don't fit in with your build. I try my best to be as helpful as I can, but even I make mistakes.
    When I was an apprentice I was told that anyone who doesn't make mistakes doesn't make anything.
    So over my 60+ years of modelling I've made a few mistakes but hopefully I've learnt something from them.
    I may be leaving the site soon because of the way the moderators were treated.
    Keep modelling, your an inspiration to many.
    Cheers Colin.
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 81 Views
    6
    ๐Ÿ’ฌ Re: Spray rails finished and other small tasksโ€ฆ.
    3 months ago by Skydive130 ( Rear Admiral)
    Flag
    Hi Colin, many thanks for that info, on the note I shall resin inside and give the outside another coat of Eze-Kote followed by filler primer. Maybe youโ€™ve saved me a disaster!

    Kind regards Sy
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 76 Views
    2
    ๐Ÿ’ฌ Re: Spray rails finished and other small tasksโ€ฆ.
    3 months ago by Colin H ( Vice Admiral)
    Flag
    Sy, what great progress you have made.
    To answer your question about resin over Ezekote.
    I tried polyester resin and it peeled in hot weather. I contacted Ezekote website and asked about my problem, they told me that any resin that wasn't water based would peel either from vibration or climate variables.
    So I always paint directly over the Ezekote with two coats of filler primer before starting on the final coats.
    Hope this helps, cheers Colin.
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 81 Views
    4
    ๐Ÿ’ฌ Re: Spray rails finished and other small tasksโ€ฆ.
    3 months ago by Skydive130 ( Rear Admiral)
    Flag
    Cheers Rick, I try my best ha ha, kind regards. Sy
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 76 Views
    1
    ๐Ÿ’ฌ Re: Spray rails finished and other small tasksโ€ฆ.
    3 months ago by Newby7 ( Vice Admiral)
    Flag
    You do nice clean work Sy
    Rick
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 79 Views
    2
    ๐Ÿ“ Chine and spray railsโ€ฆ
    3 months ago by Skydive130 ( Rear Admiral)
    Flag
    View All
    Next job was to start preparing and installing the important chine and spray rails which are vital to the boats performance. They also add some character and look pretty cool too!

    The chine rails are a piece of 1100mm 6.5mmx5mm bass word with one edge planned and sanded to a curve and run down the side of the hull from stern to bow. Once prepared, I marked the position on the hull with pencil using the measurements given in the instructions then with thick cyano and kicker glued it to the hull starting at the stern. This was a nice tight fit and only required a smidge of filler in a couple of spots to blend in.

    The spray rails of which there will be 6 in total, 3 either side of the keel are 5mm square bass wood curved on 2 edges to form a half circle. Simple job with careful use of the razor plane to take the corners off then sand paper to finish. Again the position was marked on the bottom of the hull for the first piece 35mm down from the keel and glued in the same fashion as the chine. The next 2 rails were fitted exactly the same way with 35mm separation and finished at the bow with that characteristic curve previously marked to avoid errors.

    Fitting those rails to one side has taken most of the day, I shall finish the other side tomorrow. The last job of the day and this is my impatience showing, I thought Iโ€™d stick a couple of pieces of deck wood planking and caulking towards the stern to see if I liked the result. Happy to say I do, but will not do anymore until the hull is complete and any further resin sealing is done to prevent errant splashes running the deck planks!
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comments
    ๐Ÿ‘€ 89 Views
    5
    5
    ๐Ÿ’ฌ Re: Chine and spray railsโ€ฆ
    3 months ago by Skydive130 ( Rear Admiral)
    Flag
    Hi Mike, I must admit, working with wood on the most part is a joy (apart from sheeting hulls around complex curves!), smells so much nicer than plastic, fibre glass ect.

    Kind regards Sy
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 86 Views
    1
    ๐Ÿ’ฌ Re: Chine and spray railsโ€ฆ
    3 months ago by Skydive130 ( Rear Admiral)
    Flag
    Your not Wrong Martin, wanting to get outside and finish the rails off today, but the weather forecast is looking โ€œiffyโ€ with storms possible!

    Kind regards Sy
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 86 Views
    1
    ๐Ÿ’ฌ Re: Chine and spray railsโ€ฆ
    3 months ago by mturpin013 ( Rear Admiral)
    Flag
    Hi Sy I hope this construction in wood has got rid of those feelings that hulls are made of plastic, they are not, wood is for the soul, plus it brings out all the best skills in you. - great job
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 92 Views
    3
    ๐Ÿ’ฌ Re: Chine and spray railsโ€ฆ
    3 months ago by Martin555 ( Fleet Admiral)
    Flag
    Nice smooth lines Sy.
    It is surprising how long this sort of job takes to do.

    Martin555.
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 88 Views
    1
    ๐Ÿ’ฌ Re: Chine and spray railsโ€ฆ
    3 months ago by Newby7 ( Vice Admiral)
    Flag
    Right Sy they do look cool.
    Rick
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 92 Views
    2
    ๐Ÿ“ Hull shaping, cloth and resin, oh and a standโ€ฆ.
    3 months ago by Skydive130 ( Rear Admiral)
    Flag
    View All
    Taking advantage of the weather, managed to get out into the sunshine and push forward.

    First job was to shape and sand the balsa nose blocks previously fitted and this was followed with P38 filler in any areas that need it. Once set the whole hull was sanded with various grades of sandpaper until all was perfectly smooth. Prior to fitting the cloth, I gave the hull a wipe with Panel Prep spray and a lint free cloth to ensure it was ready.

    Prior to laying the first sheet of 48gram cloth, I gave the hull a thinned coat of eze-kote and once dry a light sand and another spray of panel prep. I then cut the cloth oversized before laying on a layer of straight eze-kote with a soft 3โ€ brush. This is my first time using eze-kote and as much as itโ€™s easy to use, it sets fast, so on a large model like this you have to work fast! Once satisfied that the cloth was glued on in all areas, this was left to set for an hour before a light sand and a second coat.

    I shall leave the hull overnight before putting on the transom cloth tomorrow or friday.

    Other jobs done today have included cutting the slot for the P-frame propshaft support and making the stand from good old B&Q pvc pipe.

    The kit comes with a pre-printed deck of ply which I will not be using. Whilst it shows the distinct curved planking as fitted to the full size, I feel that at this scale I have no option but to plank the hull.

    I had some off cuts of 1.5mx8mm strip wood which when stained and with 1mm lime in between will look much better than the pre-printed affair. Iโ€™ve made up a test piece to see what it turned out like and gave it a coat of satin yacht varnish. I doubt I will use yacht varnish on this model as to be honest I hate the stuff! It takes days to dry properly at tracking dust and yellows with age. I will probably give the deck coats of Ronseal exterior varnish which drys in hours unless of course you guys have any better ideas?

    More fridayโ€ฆโ€ฆ
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comments
    ๐Ÿ‘€ 94 Views
    9
    14
    ๐Ÿ’ฌ Re: Hull shaping, cloth and resin, oh and a standโ€ฆ.
    3 months ago by Skydive130 ( Rear Admiral)
    Flag
    Hi Rob, the cloth was fairly easy to get down, but the eze-Kote doesnโ€™t allow much time for fiddling! I had a couple of creases up at the bow but got then out in time! Job done, on with all the hull chine and spray rails tomorrow, a very distinct part of the Huntsman family!

    Kind regards Sy
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 89 Views
    2
    ๐Ÿ’ฌ Re: Hull shaping, cloth and resin, oh and a standโ€ฆ.
    3 months ago by Skydive130 ( Rear Admiral)
    Flag
    Nice one will, watch my planking to see how I get on. Iโ€™m going to use the printed deck for various templates and have bought plenty of basswood 1.5mmx8mm strip along with some 1.5mmx1.5mm mahogany for the caulking although I bought all the stock my local shop had and will need Another 20x strips! Heโ€™s panic ordered some more!

    Looking at various pictures of real Huntsman, a lot seem to have light coloured sun bleached planking, so might just varnish the deck with no stain?

    Kind regards Sy
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 89 Views
    2
    ๐Ÿ’ฌ Re: Hull shaping, cloth and resin, oh and a standโ€ฆ.
    3 months ago by robbob ( Admiral)
    Flag
    Hi Sy.
    As always I'm amazed at your rate of progress ๐Ÿ˜ฎ๐Ÿ˜€
    You did well to get the glass cloth on the hull all in one piece without any serious wrinkles ๐Ÿ˜€
    Real planking is sooooo much nicer than laser etched and adds a real touch of class to any model. I found that once you got into the rhythm of layng the planks and caulking strips the process was relatively quick but always rewarding.
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 94 Views
    3
    ๐Ÿ’ฌ Re: Hull shaping, cloth and resin, oh and a standโ€ฆ.
    3 months ago by Madwelshman ( Warrant Officer)
    Flag
    You're making good headway and in my opinion, it's great to see another Fairey being built.
    A Huntsman, or any Fairey motor cruiser model with a planked deck just looks right.

    The laser etching does a job and for someone inexperienced like myself, is welcomed.
    I will be having a 1st attempt at planking the deck of one of my Faireys at some point.

    Will
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 91 Views
    2
    ๐Ÿ’ฌ Re: Hull shaping, cloth and resin, oh and a standโ€ฆ.
    3 months ago by Skydive130 ( Rear Admiral)
    Flag
    Cheers Rick ๐Ÿ‘
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 92 Views
    1
    ๐Ÿ’ฌ Re: Hull shaping, cloth and resin, oh and a standโ€ฆ.
    3 months ago by Newby7 ( Vice Admiral)
    Flag
    Looking good Sy moving along nicely.
    Rick
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 95 Views
    2
    ๐Ÿ’ฌ Re: Hull shaping, cloth and resin, oh and a standโ€ฆ.
    3 months ago by Skydive130 ( Rear Admiral)
    Flag
    Hi Geoff, another idea to think about, thank you

    Sy
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 93 Views
    1
    ๐Ÿ’ฌ Re: Hull shaping, cloth and resin, oh and a standโ€ฆ.
    3 months ago by Skydive130 ( Rear Admiral)
    Flag
    Cheers Colin, will google that stuff, kind regards Sy
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 93 Views
    1
    ๐Ÿ’ฌ Re: Hull shaping, cloth and resin, oh and a standโ€ฆ.
    3 months ago by mistyoptic ( Midshipman)
    Flag
    I find Rustins Outdoor Clear Varnish very good, dries in 30 minutes, can be thinned with water if required and brush wash up with water.

    Geoff
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 93 Views
    2
    ๐Ÿ’ฌ Re: Hull shaping, cloth and resin, oh and a standโ€ฆ.
    3 months ago by Colin H ( Vice Admiral)
    Flag
    Sy, Le Tonkinois Marine No 1 Varnish.
    Gives that glass coated look and it goes on well, but you need to do 1 coat a day with rubbing down between coats, I usually give 6 coats and a final polish with Farecla finishishing compound available at most Good auto paint suppliers.
    I know it's a slow process but it's worthwhile and lasts for years.
    Cheers Colin.
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 97 Views
    2
    ๐Ÿ’ฌ Re: Hull shaping, cloth and resin, oh and a standโ€ฆ.
    3 months ago by Skydive130 ( Rear Admiral)
    Flag
    Hi Martin, I was thinking about using resin, the z poxy stuff Iโ€™ve got. I need to research it to see if itโ€™s an option unless none has tried it before? What I would like to achieve is that glass like finish you see on post yachts !

    Kind regards Sy
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 94 Views
    2
    ๐Ÿ’ฌ Re: Hull shaping, cloth and resin, oh and a standโ€ฆ.
    3 months ago by Colin H ( Vice Admiral)
    Flag
    That's handy to know Nerys, I've used it for furniture repairs and Caroline's dolls houses but never thought about the model boats.
    Cheers Colin.
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 97 Views
    3
    ๐Ÿ’ฌ Re: Hull shaping, cloth and resin, oh and a standโ€ฆ.
    3 months ago by Nerys ( Fleet Admiral)
    Flag
    In the days when ply was the normal product to build dinghies, it was quite common to paint the whole of the interior with an adhesive called Cascamite. This was a powder that was mixed with water to become a waterproof adhesive. Like resin, it dried clear. I built several small boats with it even using it in the main construction. I see no reason why it should not be used to coat the interior of a model boat in fact it could be easier than resin as it does not go off quickly. I've seen it on sale in Axminster Tools, so I'm sure it is still readily available.

    Cheers, Nerys
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 94 Views
    3
    ๐Ÿ’ฌ Re: Hull shaping, cloth and resin, oh and a standโ€ฆ.
    3 months ago by Martin555 ( Fleet Admiral)
    Flag
    Hi Sy,
    Instead of using varnish for the wood could you use resin ?
    Looking forward to the next update.

    Martin555.
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 92 Views
    2
    ๐Ÿ“ Transom and false deckโ€ฆ,
    3 months ago by Skydive130 ( Rear Admiral)
    Flag
    View All
    The last of days excellent weather has given me plenty of time to get outside and press onโ€ฆ.

    The first job was to sand, seal, spray paint and lacquer the motor mount, which now has the motor fitted and I consider finished and ready to install.

    After that I prepared and shaped the stern of th3 boat to receive the transom ply sheet. Prior to fitting that sheet, I fitted 2 water cooling outlets above the guestimated waterline which were sealed with epoxy and had the tubing fitted as it will be nigh on impossible to fit after. The transom sheet was then glued on and taped into position to be left overnight to set.

    Whist waiting for the transom to set, I painted in some finishing resin inside the hull into the parts that will be impossible to reach once the deck is on. I will give the internals another full coat of resin followed by a coat of Hammerite silver paint in due course.

    The only job today after work was to glue and fit the false deck and tape, clamp and weight it into position making sure that contact points were glued.

    That will be it until Wednesday when I will start sanding and filling the the hull ready to cloth along with making the motor mount plate, esc, Rx and servo mountโ€ฆโ€ฆ
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comments
    ๐Ÿ‘€ 96 Views
    9
    5
    ๐Ÿ’ฌ Re: Transom and false deckโ€ฆ,
    3 months ago by Martin555 ( Fleet Admiral)
    Flag
    Hi SY,
    She is really taking shape now.

    Martin555.
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 94 Views
    1
    ๐Ÿ’ฌ Re: Transom and false deckโ€ฆ,
    3 months ago by Skydive130 ( Rear Admiral)
    Flag
    Cheers Rick, that hardness part is done, almost onto the fun stuff!

    Kind regards Sy
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 96 Views
    1
    ๐Ÿ’ฌ Re: Transom and false deckโ€ฆ,
    3 months ago by Newby7 ( Vice Admiral)
    Flag
    Nicely done SY.
    Rick
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 96 Views
    2
    ๐Ÿ’ฌ Re: Transom and false deckโ€ฆ,
    3 months ago by Skydive130 ( Rear Admiral)
    Flag
    Cheers Colin, everything about the kit is nice, from the quality of the wood to the fit, hats off to SLEC!

    Kind regards Sy
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 96 Views
    2
    ๐Ÿ’ฌ Re: Transom and false deckโ€ฆ,
    3 months ago by Colin H ( Vice Admiral)
    Flag
    Nicely done Sy, that transom is a good fit sir, keep it going.
    Cheers Colin.
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 99 Views
    3
    ๐Ÿ“ Sheeting completed, onwards and upwards!
    3 months ago by Skydive130 ( Rear Admiral)
    Flag
    View All
    Good day in the sunshine! First job this morning was to make sure that all the previous sheeting and chine rails were shaped and sanded ready to receive the last side sheet. Last night I prepared the last side sheet by soaking the curved bow end in boiling hot water in a baking tray on the cooker and then when pliable, curved it round a Halfords spray can and taped overnight to dry the curve in.

    Once happy that everything was ready to receive the sheet, I again marked the areas which would be glued on the sheet, chines and any other glue points. Again the sheet was fitted using contact adhesive less the curved bow section which was glued with medium and thick cyano and kicker. Within a few minutes, the sheet was in position hopefully never to part company and all glue joints were reinforced with PVA and in some areas epoxy for belt and braces. This will all be left overnight before shaping and sanding.

    Other jobs was to fit the 3 laminations of balsa sheet which form a curved base (when shaped) for the false deck at the transom and also increase the glue area for the transom sheet which hopefully will be fitted tomorrow after the rear end of the boat has been shaped ready to receive it.

    I also fitted the 2 rough shaped balsa blocks at the bow which when shaped, sanded and filled will form that nice curved bow the Huntsman is famous for. That area will need quite a bit of work to get it ready for the cloth to be applied to the hull, but will be worth the graft.

    Before I fit the transom sheet I plan on marking tHe water line on it so that I can gauge where I am going to have the twin water cooling outlets which I need to fit prior to fitting the sheet. If I donโ€™t, it will be nigh on impossible to fit the tubing later as that area is just about impossible to reach from inside the hull once the transom is fitted.

    See you tomorrowโ€ฆ..
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comments
    ๐Ÿ‘€ 97 Views
    7
    2
    ๐Ÿ’ฌ Re: Sheeting completed, onwards and upwards!
    3 months ago by Skydive130 ( Rear Admiral)
    Flag
    Your not wrong Martin, sunshine, sawdust and a cup of tea outside, winner! It also helps being outside as the boat is as long as my workbench!
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 96 Views
    2
    ๐Ÿ’ฌ Re: Sheeting completed, onwards and upwards!
    3 months ago by Martin555 ( Fleet Admiral)
    Flag
    Coming along nicely Sy,
    It is nice to have a bit of good weather to be able to work outside.

    Martin555.
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 94 Views
    1
    ๐Ÿ“ Sheeting continuesโ€ฆ.
    3 months ago by Skydive130 ( Rear Admiral)
    Flag
    View All
    So, I managed to sneak the second bottom sheet on last night before bed giving that overnight to set.

    This morning I trimmed, shaped and sanded the bottom sheets ready to receive the dreaded side sheets. Before anything else, I filed out the prop shaft exit and the hole leading to the rudder tube and check them in place for a good fit. One thing I have ordered today is a brass p-frame bracket as the prop shaft is only 6.30mm dia and would be very vulnerable to damage or bending if left hanging out in the breeze as you can see in the picture!

    Having re-read the instructions, it recommended using contact adhesive to bond the sheets to the frames, ok, Iโ€™ll give that a go! First of all though, as recommended I added some doublers to the frames to give the sheeting more to grab onto and then set about marking the sheet weโ€™re it was to make contact with the frames. I then put a coat of contact adhesive on all the frames except the curved front 2 and the chines and the marked side sheet. Leaving this for 10 minutes gave me a chance to grab the clamp box ready to bond the sheet on. And bond it did! You only get one shot, so with a couple of alignment marks Iโ€™d made, I offered up the sheet to the frames and started to bond and clamp it.

    The instructions recommended using cyano and kicker for the curved formers and front chines and with a bit of brute force and muscle power, managed to get the curved parts bonded. I left the whole lot a couple of hours to set and then smeared Gorilla PVA into all the joints for added strength.

    Iโ€™m now at a point weโ€™re I need a break, so as Iโ€™m back at work tomorrow and Friday, I shall leave the final sheet and transom sheet until the weekend. Once they are on, itโ€™s a case of adding the front balsa blocks followed by sanding, filler, more sanding before adding the false deck and getting ready to glass cloth.

    See you at the weekendโ€ฆโ€ฆ..
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comments
    ๐Ÿ‘€ 99 Views
    5
    2
    ๐Ÿ’ฌ Re: Sheeting continuesโ€ฆ.
    3 months ago by Skydive130 ( Rear Admiral)
    Flag
    You do see the doublers Colin, great tip, helped a lot, thank you very much ๐Ÿ‘
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 99 Views
    2
    ๐Ÿ’ฌ Re: Sheeting continuesโ€ฆ.
    3 months ago by Colin H ( Vice Admiral)
    Flag
    Sy, Looks like you are getting the shape really well, do I see the doublers on the bulkhead edges.
    Going really well sir.
    Cheers Colin.
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 101 Views
    3
    ๐Ÿ“ The battle of the skins!โ€ฆโ€ฆ
    4 months ago by Skydive130 ( Rear Admiral)
    Flag
    View All
    Last night after work, I set about shaping and glueing the transom supports which consisted of 8 pieces. All that was required was a bevel sanded where the pieces met the keel, then glued and clamped and let to set overnight.

    Todayโ€™s task was the prepare the bulkheads and keel ect in readiness for the hull sheeting. Shaping the chines and keel was easy enough to achieve with the razor plane, dremel sanding drum and finally the sanding block although quite time consuming but reasonably pleasant in the sunshine!

    Then it was onto the first of the sheets which is a job that fills me with utter hatred! I donโ€™t know why, but itโ€™s always a battle to get them fitted well to all the bulkheads ect. According to the instructions, the sheets are fitted bottom of hull. First and then the side pieces. Also according to the instructions it states that the side sheets are harder to fit, great, the bottom ones are hard enough!

    I test fitted the first sheet to make sure it was touching all the right parts and then did a practice run with the clamps, all seemed reasonably good. I then followed up with PVA to all the contact parts on the keel and put on the first sheet quickly clamping with as many clamps as possible to keep it in position and also checking to make sure the hull is still squared. I drew lines on the sheet where the bulkheads are running underneath and with my trusty pin pusher and 12mm brass nails, pushed them into the sheet and into the bulkheads to make sure they were contacting the curved bulkheads towards the bow. Itโ€™s a bit trial and error with the pin pusher, some hit, some donโ€™t but once youโ€™ve got enough into the sheet over the bulkheads, they ,work. Once happy that all the wood was contacting weโ€™re needed, I ran a bead of PVA into all the joints with a mark 1 finger and will now leave this to set over night before sheet 2 tomorrowโ€ฆ.
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comments
    ๐Ÿ‘€ 100 Views
    8
    35
    ๐Ÿ’ฌ Re: The battle of the skins!โ€ฆโ€ฆ
    3 months ago by Geoffrhoose ( Recruit)
    Flag
    I agree excellent products.
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 40 Views
    ๐Ÿ’ฌ Re: The battle of the skins!โ€ฆโ€ฆ
    3 months ago by Colin H ( Vice Admiral)
    Flag
    I thought that would have been the case, (or are you building a full size version. On the qt.)
    Cheers Colin.
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 100 Views
    1
    ๐Ÿ’ฌ Re: The battle of the skins!โ€ฆโ€ฆ
    3 months ago by Skydive130 ( Rear Admiral)
    Flag
    Colin, when I said I was using 48oz cloth, what I meant was 48gsm cloth, so no, Iโ€™m not using ultra heavyweight canvas ro cover the hull ๐Ÿ˜‚๐Ÿ˜‚๐Ÿ˜‚

    Kind regards. Sy
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 99 Views
    2
    ๐Ÿ’ฌ Re: The battle of the skins!โ€ฆโ€ฆ
    3 months ago by Skydive130 ( Rear Admiral)
    Flag
    Hi Bill, work gets in the way of modelling if Iโ€™m honest, thankfully I only work 3-4 days a week now so get plenty of time off. But yes, going to work does give me a break then I can come back at the modelling reinvigorated ha ha!

    Kind regards Sy
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 97 Views
    1
    ๐Ÿ’ฌ Re: The battle of the skins!โ€ฆโ€ฆ
    4 months ago by Scratchbuilder ( Captain)
    Flag
    Amazing Sy.
    I think Iโ€™ve said it before but with the amount of time you dedicate to your masterpieces do you go to work for a rest?
    Regards Bill.
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 101 Views
    2
    ๐Ÿ’ฌ Re: The battle of the skins!โ€ฆโ€ฆ
    4 months ago by Skydive130 ( Rear Admiral)
    Flag
    Cheers Martin, a good idea indeed but Colin suggested doublers which will mean less drilling and filling later. But thank you one and all for your input, every little helps. ๐Ÿ‘
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 97 Views
    1
    ๐Ÿ’ฌ Re: The battle of the skins!โ€ฆโ€ฆ
    4 months ago by Skydive130 ( Rear Admiral)
    Flag
    Great idea Colin, I shall add some doublers ๐Ÿ‘
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 97 Views
    1
    ๐Ÿ’ฌ Re: The battle of the skins!โ€ฆโ€ฆ
    4 months ago by Martin555 ( Fleet Admiral)
    Flag
    Sy,
    Maybe you could drill a hole through the form and a couple of holes through the skin then with some cable ties or strong string you could pull the skins in hard to the form until the glue dries.
    I know you will have to fill the hols later.

    Martin555.
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 96 Views
    2
    ๐Ÿ’ฌ Re: The battle of the skins!โ€ฆโ€ฆ
    4 months ago by Colin H ( Vice Admiral)
    Flag
    Sy, in places where you have compound curves such as your Fairey, I add doublers to the edge of the bulkheads. 1/4inch Square. Glued and pinned, this gives a good solid area to put screws or pins.
    Cheers Colin.
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 99 Views
    3
    ๐Ÿ’ฌ Re: The battle of the skins!โ€ฆโ€ฆ
    4 months ago by Skydive130 ( Rear Admiral)
    Flag
    Hi Martin,

    The issue I have is the thickness of the bulkhead formers, they arenโ€™t thick enough to take a screw.
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 97 Views
    2
    ๐Ÿ’ฌ Re: The battle of the skins!โ€ฆโ€ฆ
    4 months ago by Martin555 ( Fleet Admiral)
    Flag
    Hi Sy,

    I have recently done a bit of skinning up and i found i had to use some small wood screws to hold the skin in place around the bow.
    When the glue had dried i removed the screws then glued cocktail sticks in to fill the holes.
    the sticks were then cut flush ready for sanding.

    Martin555.
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 96 Views
    2
    ๐Ÿ’ฌ Re: The battle of the skins!โ€ฆโ€ฆ
    4 months ago by Skydive130 ( Rear Admiral)
    Flag
    Hi JB, that sounds like a great idea.

    My next issue is when fitting the side ply sheets there is quite an inward curve on the bow bulkheads that the ply has to bend too. I think I need to try and pre-curve the ply with hot water and the heat gun otherwise I will rage trying to get the ply sheet in position! Let the fun begin!
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 97 Views
    2
    ๐Ÿ’ฌ Re: The battle of the skins!โ€ฆโ€ฆ
    4 months ago by jbkiwi ( Fleet Admiral)
    Flag
    Sy, just a suggestion,- what I do, is once everything is lined up and sized, I drill 2 (firm fitting) locating dowel holes (say- transom and mid keel) with the planks clamped in the correct position (small pointed bamboo skewers are good). Make a couple of small dowels (10mm) with a point on both ends and push them into the holes (leaving 5mm protruding). Remove the sheet and re apply to check. This will make locating and clamping the sheets spot on first time, with no worries about them moving (works for decks as well)

    Alternatively, you can drill the holes, apply the glue, then push pointed dowels in to locate, but I've found fixing the dowels first is easier.

    I apply the PVA or balsa glue as usual, and leave say 5mm gaps every so often for a blob of thick Cyano. This will grab quickly when the plank is clamped and hold things in case the clamps move. The dowels can be sanded off later. When you run the resin round the inside, it will fill up any gaps and glue everything solidly, (also seals and waterproofs PVA,)- I've found that even a good coating of dope, -then painted,- will do that as well.

    JB
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 97 Views
    3
    ๐Ÿ’ฌ Re: The battle of the skins!โ€ฆโ€ฆ
    4 months ago by Colin H ( Vice Admiral)
    Flag
    Sy, 48oz? Very heavy duty, the heaviest I ever used was 24oz to build myself a fishing Kayak.
    So I don't think you will ever break this one.
    Cheers Colin.
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 99 Views
    2
    ๐Ÿ’ฌ Re: The battle of the skins!โ€ฆโ€ฆ
    4 months ago by Skydive130 ( Rear Admiral)
    Flag
    Many thanks for the tips Colin. I shall give the bare wood a coat of thinned resin in the first instance then a couple of coats neat as suggested. Iโ€™m using a slightly heavier 48oz cloth as itโ€™s a large model, so may need more to fill the weave.

    Kind regards Sy
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 97 Views
    2
    ๐Ÿ’ฌ Re: The battle of the skins!โ€ฆโ€ฆ
    4 months ago by Colin H ( Vice Admiral)
    Flag
    Sy, I usually thin my first coat 1 part water 2 parts Ezekote, then any further coats neat. I use 25gsm glass cloth and I have also used a pair of ladies tights(with permission)
    Which follows the Hull shape really well without having any overlaps or joints.
    Also ezekote mixed with some fine sanding dust makes a great filler paste that sets hard and bonds well without shrinkage.
    Hope this helps Colin.
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 100 Views
    4
    ๐Ÿ’ฌ Re: The battle of the skins!โ€ฆโ€ฆ
    4 months ago by Skydive130 ( Rear Admiral)
    Flag
    I dare say Doug will pop in and advise when he sees the post Pete ๐Ÿ‘Œ
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 98 Views
    2
    ๐Ÿ’ฌ Re: The battle of the skins!โ€ฆโ€ฆ
    4 months ago by Rookysailor ( Commodore)
    Flag
    Hi Sy, I believe that Doug mentioned something about thinning it down for the first coat to let it sink in, just wish I could find the post that it relates to.

    Cheers, Pete๐Ÿ˜
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 100 Views
    2
    ๐Ÿ’ฌ Re: The battle of the skins!โ€ฆโ€ฆ
    4 months ago by Skydive130 ( Rear Admiral)
    Flag
    Hi Mike and welcome aboard! Many thanks for your input, hopefully things will stay stuck with waterproof pva and all the other layers of cloth, resin paint ect.

    Iโ€™ve got a bottle of that eze cote resin which I am going to use for the first time on this model. Iโ€™ve always used 2 part finishing resin but that stuff is expensive and doesnโ€™t go far, especially on a model this size. I did a little experiment with the eze cote the other day on a piece of ply and a scrap piece of glass cloth. I gave the wood a cote of resin, sanded it smooth when dry then added the cloth and another coat of resin. Once dried, sanded that smooth and gave the cloth a further 2 coats with sanding between followed by a coat of red oxide primer, I was quite pleased with the finish. I used the resin neat, do I need to thin it? What I do like is the quick drying time and lack of smell, oh and the brush washes out in water, win win I say!

    Any tips gratefully received before I get to the clothing stage.

    Kind regards Sy
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 98 Views
    2
    ๐Ÿ’ฌ Re: The battle of the skins!โ€ฆโ€ฆ
    4 months ago by mturpin013 ( Rear Admiral)
    Flag
    Hi Sy I'm sure with the addition of glass in the overall process it will stay glued together.
    However for future reference I would use epoxy 30 minute set for all the construction of the main frame and skins and as Rob says Hammarite for the internal wood after a coat of Deluxe Materials Eze Kote Finishing Resin (diluted)
    PS I use smooth hammarite in cream as it lightens up the internals, I know Rob uses silver in a hammered finish.
    All in all its looking good
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 101 Views
    3
    ๐Ÿ’ฌ Re: The battle of the skins!โ€ฆโ€ฆ
    4 months ago by Skydive130 ( Rear Admiral)
    Flag
    In fact Rob, Iโ€™ve gotta pass B&Q on way home Thursday, so Iโ€™ll take the smooth back and get the hammered ๐Ÿ‘
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 98 Views
    2
    ๐Ÿ’ฌ Re: The battle of the skins!โ€ฆโ€ฆ
    4 months ago by Skydive130 ( Rear Admiral)
    Flag
    I saw the hammered effect stuff on the shelf, Iโ€™ll get some next time Iโ€™m in B&Q Rob ๐Ÿ‘
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 98 Views
    2
    ๐Ÿ’ฌ Re: The battle of the skins!โ€ฆโ€ฆ
    4 months ago by robbob ( Admiral)
    Flag
    Hi Sy.
    I have used the expanding type Gorilla Glue for joinery work and that's very good as it expands into the grain and fills any gaps in yer mortice and tenon joints, (yes..... I can still make all the joints I was taught in woodwork class ๐Ÿ˜Š) but I've not used their PVA though.

    Hammerite...that is indeed the stuff I used inside my Crash Tender, but I used the 'hammered effect' finish as it's more tolerant of brush marks.
    Once it has dried and 'cured' it's makes for a very hard, durable and waterproof finish.
    Rob.
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 104 Views
    3
    ๐Ÿ’ฌ Re: The battle of the skins!โ€ฆโ€ฆ
    4 months ago by Martin555 ( Fleet Admiral)
    Flag
    SY,
    I have been saying for a long time now that i am not right LOL!!

    Martin555.
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 97 Views
    1
    ๐Ÿ’ฌ Re: The battle of the skins!โ€ฆโ€ฆ
    4 months ago by Colin H ( Vice Admiral)
    Flag
    That's the same paint I use Sy,
    Cheers Colin.
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 100 Views
    2
    ๐Ÿ’ฌ Re: The battle of the skins!โ€ฆโ€ฆ
    4 months ago by Skydive130 ( Rear Admiral)
    Flag
    Hi Colin, always happy for peopleโ€™s input and comments, itโ€™s what the hobby is all about, learning and sharing the knowledge.
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 98 Views
    1
    ๐Ÿ’ฌ Re: The battle of the skins!โ€ฆโ€ฆ
    4 months ago by Skydive130 ( Rear Admiral)
    Flag
    Martin, you must surly be tapped in the head if you think sheeting is fun, I hate it with a passion !๐Ÿ˜‚๐Ÿ˜‚๐Ÿ˜‚. Iโ€™ll be glad when itโ€™s done, sanded, filled and glassed, never to be seen again lol

    Kind regards Sy
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 98 Views
    1
    ๐Ÿ’ฌ Re: The battle of the skins!โ€ฆโ€ฆ
    4 months ago by Skydive130 ( Rear Admiral)
    Flag
    View All
    Hi Rob,

    Iโ€™ve been using Gorilla PVA recently as itโ€™s waterproof, sands like aliphatic and sets hard fast, really like it. Can I confirm the Hammerite paint I bought today pictured is the same stuff you use to great effect?

    Kind regards Sy
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 98 Views
    3
    ๐Ÿ’ฌ Re: The battle of the skins!โ€ฆโ€ฆ
    4 months ago by Martin555 ( Fleet Admiral)
    Flag
    I will admit Sy this is a fun bit LOL!
    I am sure you will conquer it.

    Martin555.
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 97 Views
    1
    ๐Ÿ’ฌ Re: The battle of the skins!โ€ฆโ€ฆ
    4 months ago by robbob ( Admiral)
    Flag
    View All
    Very rapid progress as we've all come to expect from you Sy ๐Ÿ‘๐Ÿ˜€.

    I'm following your build with great interest as I very nearly bought the same kit.

    I have always used Titebond II PVA glue which is 'water resistant' and far better that ordinary white PVA which is definitely not!

    There is also Titebond III which is apparently a 'waterproof' PVA if you really want 'belt 'n braces'.

    With the hull properly sealed with fibreglass and resin externally and a thorough paint finish internally I don't think you will have much to worry about.
    KUTGW ๐Ÿ‘๐Ÿ‘.
    Rob.
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 104 Views
    4
    ๐Ÿ’ฌ Re: The battle of the skins!โ€ฆโ€ฆ
    4 months ago by Colin H ( Vice Admiral)
    Flag
    Sy, it sounds like you've got it fully figured out, so I'll stop putting doubts in your head.
    Great job so far and I'm sure it'll be a very special model when finished.
    Cheers Colin.
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 100 Views
    2
    ๐Ÿ’ฌ Re: The battle of the skins!โ€ฆโ€ฆ
    4 months ago by Skydive130 ( Rear Admiral)
    Flag
    Hi Colin, fingers crossed my use of PVA should be fine. The hull will be glass clothed and resin and painted on the outside and the inside will get a coat of resin followed by a coat of Hammerite paint which hopefully will mean the PVA will never come into contact with water. Of course I hope never to capsize the model either but you never know!

    Kind regards Sy
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 98 Views
    2
    ๐Ÿ’ฌ Re: The battle of the skins!โ€ฆโ€ฆ
    4 months ago by Colin H ( Vice Admiral)
    Flag
    Sy it's getting this part right that helps give the model its strength, looks like you are coping well so far.
    My only concern is your use of pva adhesive. I was given a model to repair that was built a couple of years ago using industrial waterproof pva, but after it capsized almost every joint opened up within half an hour.
    I had one hell of a job rebuilding it.
    Cheers Colin.
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 100 Views
    2
    ๐Ÿ’ฌ Re: The battle of the skins!โ€ฆโ€ฆ
    4 months ago by Skydive130 ( Rear Admiral)
    Flag
    I see what you mean Nerys, could be a bird house ha ha ๐Ÿ˜‚๐Ÿ‘
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 99 Views
    2
    ๐Ÿ’ฌ Re: The battle of the skins!โ€ฆโ€ฆ
    4 months ago by Nerys ( Fleet Admiral)
    Flag
    Please forgive me for saying this, but from the first photo I thought you were building an elaborate two room bird house.

    Nerys
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 99 Views
    2
    ๐Ÿ“ Fitting the keel and chine rails โ€ฆ
    4 months ago by Skydive130 ( Rear Admiral)
    Flag
    View All
    I have managed to achieve what I set out to do today before the start of a certain footie match this evening!

    First job having glued up all the keel parts yesterday was to check the prop shaft passed through its slot ok and to to drill out the hole for the rudder post, easy enough. Once done, I cleaned out with the files, the slots on the keel and the bulk heads before fitting the keel to the models frames, checking for true on every angle possible before again painting in part diluted gorilla PVA glue into all the joints and giving a second coat to other joints already glued.

    After lunch I was in the position to start fitting the chine rails. There are 2 obechi rails each side of the hull and each chine is made of 2 strips to aid bending. Clamps are good for a lot of things, but Iโ€™ve always struggled in the past to get clamps on to chines without them pinging off at the wrong moment! What I do now is to use thick cyano for the first run and then using a pin pusher and 12mm brass nails left over from model display ships, pin the chine at each point it touches a bulkhead. Works every time!

    I gave that an hour to really set (distracted my impatience by cutting the grass!)before adding the second runs with PVA and every clamp I have (must get more, you can never have enough!). Then finally, again made sure everything was square and true before leaving to set. At this point, if we are out of square, it will be a lot harder to straighten although it can be done when we sheet the hull, although Iโ€™d rather avoid it!

    Thatโ€™s it until Tuesday when I will fit the transom supports and start sheetingโ€ฆ.
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comments
    ๐Ÿ‘€ 106 Views
    6
    5
    ๐Ÿ’ฌ Re: Fitting the keel and chine rails โ€ฆ
    4 months ago by Colin H ( Vice Admiral)
    Flag
    Sy, look for reusable ties they are great and no waste.
    Cheers Colin.
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 107 Views
    2
    ๐Ÿ’ฌ Re: Fitting the keel and chine rails โ€ฆ
    4 months ago by Skydive130 ( Rear Admiral)
    Flag
    Good tip with the cable ties nerys, Iโ€™ll keep that one in the mental bank for the future, Iโ€™ve hundreds of the little plastic blighters lol.

    Kind regards Sy
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 106 Views
    2
    ๐Ÿ’ฌ Re: Fitting the keel and chine rails โ€ฆ
    4 months ago by Nerys ( Fleet Admiral)
    Flag
    She's a big old boat, Sy, but you seem to be getting on well with her. As you say, one can never have enough cramps but they don't work when fitting chines, I find that cable ties can be quite helpful.

    Cheers, Nerys
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 105 Views
    3
    ๐Ÿ’ฌ Re: Fitting the keel and chine rails โ€ฆ
    4 months ago by Skydive130 ( Rear Admiral)
    Flag
    Iโ€™m switching the iPad off Rick, I need no distractions, the chines are ok,a I just checked ๐Ÿ˜‚๐Ÿ˜‚๐Ÿ˜‚
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 107 Views
    1
    ๐Ÿ’ฌ Re: Fitting the keel and chine rails โ€ฆ
    4 months ago by Newby7 ( Vice Admiral)
    Flag
    Hi Sy The chine will look after its self. The game whistle is more important.
    Rick
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 108 Views
    2
    ๐Ÿ“ Let building commenceโ€ฆ.
    4 months ago by Skydive130 ( Rear Admiral)
    Flag
    View All
    So, starting on the huge Huntsman initially starting with preparing all the laser cut parts that make up the keel and bulkheads. All parts required were cut from the sheets and marked up to avoid mistakes later. Due to the quality of the SLEC laser cutting, the parts required minimal preparation, with a gentle sand both sides of each part and ensuring the cut lugs were sanded flush. One other thing I did which I feel is important for a good fit was to square file the round slots so that when the bulkheads were pushed onto their side former sheets they sat true. Once happy all parts were prepared properly and after a โ€œDry no glue fitโ€ to make sure everything was right I started gluing the bulkheads onto the side sheets and also bonded the 6.5mm square hardwood rails to formers and side sheets. Everything was initially tacked with cyano then with the false deck fitted (not glued at this stage, that comes much later) I then went round each joint with slightly thinned waterproof PVA with a brush giving itโ€™s first coat of glue. I will give all joints a second coat tomorrow.

    At this point, I decided to make up the motor mount as I intend to fit the propshaft earlier in the build than described in the destructions. The motor mount is again a laser cut affair and will be the perfect fit for my motor as the already drilled holes for the mount mount plate are perfectly aligned.

    Last job was to prepare all the parts for the keel which includes several doublers for the rudder post and propshaft guide slot. The instructions stated that the propshaft slot is drilled once all the doublers are fitted, however I decided for ease and accuracy that I would fit the 2 doublers on one side of the main keel, add the second keel layer than cut out with the dremel 2x pieces inside the propshaft channel that are there to make sure that the keel stays inline when fitting the doublers. Once I did that, I checked the propshaft fitted ok and then added the remaining doublers, clamped it and thatโ€™s to be left overnight for a solid bond.

    More tomorrowโ€ฆ..
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comments
    ๐Ÿ‘€ 111 Views
    8
    12
    ๐Ÿ’ฌ Re: Let building commenceโ€ฆ.
    4 months ago by Skydive130 ( Rear Admiral)
    Flag
    Colin, thank you so much for those pictures and link, there is some superb reference pics there that will come in very useful.

    Curious to see the price she sold for, not a lot in my eyes although it would neeed money thrown at it to bring her back to standards and then the running and mooring costs after! Iโ€™d love a boat like that, but fear it would be a money pit, maybe Iโ€™ll rent one for a holiday in the next couple of years ๐Ÿ‘

    Kind regards Sy
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 106 Views
    2
    ๐Ÿ’ฌ Re: Let building commenceโ€ฆ.
    4 months ago by Colin H ( Vice Admiral)
    Flag
    View All
    Good afternoon Sy, I thought these pics mihgt give you some ideas.
    I wish I was a boy again, my dad rented us a Swordsman for the 1969 boatshow lived aboard for 10 Days, and cruised the south coast and round the Isle of White. VERY HAPPY DAYS!!!!!
    Cheers Colin.
    http://prestonmarina.co.uk/index.php/fairey-huntsman-31-sabr...
    http://prestonmarina.co.uk/index.php/fairey-huntsman-31-sabre-knight-refit-project-opportunity/
    ๐Ÿ”—
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 109 Views
    3
    ๐Ÿ’ฌ Re: Let building commenceโ€ฆ.
    4 months ago by Skydive130 ( Rear Admiral)
    Flag
    Cheers Rick, I am to please ๐Ÿ˜‚
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 106 Views
    1
    ๐Ÿ’ฌ Re: Let building commenceโ€ฆ.
    4 months ago by Newby7 ( Vice Admiral)
    Flag
    Hi Sy Off to a good start.
    Rick
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 108 Views
    2
    ๐Ÿ’ฌ Re: Let building commenceโ€ฆ.
    4 months ago by Skydive130 ( Rear Admiral)
    Flag
    Hi Bill and welcome aboard again, hopefully Iโ€™ll do my best to keep you entertained!

    Kind regards Sy
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 108 Views
    1
    ๐Ÿ’ฌ Re: Let building commenceโ€ฆ.
    4 months ago by Scratchbuilder ( Captain)
    Flag
    Morning Sy.
    Looking good and another worthwhile project that will keep us all enthralled.
    Keep it up.
    Regards Bill.
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 114 Views
    2
    ๐Ÿ’ฌ Re: Let building commenceโ€ฆ.
    4 months ago by Skydive130 ( Rear Admiral)
    Flag
    Hi Doug and welcome aboard. I was looking at different Fairey logos ect last night and your right at some point I will need them. Due to the big scale of this model though and I will probably go with a standard blue and white scheme, Iโ€™m hoping I can find someone who makes decals in vinyl. Thankfully the Huntsman 31 doesnโ€™t often appear with lots of logos and decals ect, unlike the smaller 28 which often does.

    Iโ€™ll worry about that down the line, but another issue I have is what to do about the deck planking? The kit comes with a pre-printed deck representing the curved planks of the real thing. I want to lay down planking strips with white plastic of lime caulking but have no idea how to do the curved planks, straight ones would be a doddle!

    Again Iโ€™ll put that thought out there in a week or 2 when Iโ€™m closer to deck planking.

    Kind regards Sy
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 109 Views
    1
    ๐Ÿ’ฌ Re: Let building commenceโ€ฆ.
    4 months ago by RNinMunich ( Fleet Admiral)
    Flag
    View All
    So far so very good Sy ๐Ÿ‘
    Figure you might need some of these at some stage - see pics.
    Cheers, Doug ๐Ÿ˜Ž
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 119 Views
    2
    ๐Ÿ’ฌ Re: Let building commenceโ€ฆ.
    4 months ago by Skydive130 ( Rear Admiral)
    Flag
    Indeed Colin, there is something about the classic lines of Fairey boats thatโ€™s just so pleasing on the eye

    Kind regards Sy
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 111 Views
    1
    ๐Ÿ’ฌ Re: Let building commenceโ€ฆ.
    4 months ago by Colin H ( Vice Admiral)
    Flag
    Sy, that's a good start to your new boat,a big beast but a beautiful shape.
    Cheers Colin.
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 114 Views
    2
    ๐Ÿ’ฌ Re: Let building commenceโ€ฆ.
    4 months ago by Skydive130 ( Rear Admiral)
    Flag
    Hi Martin, yes, all is aligned nicely, the keel will go in tomorrow along with the chine rails prior to sheeting, that much loved job ๐Ÿ˜‚

    As for the smoker unti, that has kept me off the fags for 7 years lol,

    Kind regards Sy
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 111 Views
    1
    ๐Ÿ’ฌ Re: Let building commenceโ€ฆ.
    4 months ago by Martin555 ( Fleet Admiral)
    Flag
    Off to a great start Sy,

    Did you use the keel to double check alignment ?

    I see you have a smoker unit already assembled on the bench. LOL!!!

    Martin555.
    ๐Ÿ‘ Like
    ๐Ÿ’ฌ Comment
    ๐Ÿ‘€ 113 Views
    1
    Show 1 More Posts


    About This Website
    Terms of Service
    Privacy Policy
    Cookies used in this website are gluten free, wheat free and dairy free. By using this website you agree to our use of cookies. More Info
