Model Boats Website
Mark me out of 10
3 Photos · 1 Like · 2 Comments
Boat Length
67" (170.18 cm)
6 years ago by 🇬🇧 steve-d
Just starting build. 10 Rater sharpie. Design name Maree III (5/10)
▲
⟩⟩
EdW
|
💬 Re: Mark me out of 10
1 year ago by 🇬🇧 steve-d (
 Warrant Officer)✧ 29 Views · 3 Likes
Flag
Now the hull.
The frames are just a jig and get removed. Later strategic frames/bulkheads get fitted. One close-up shows where the keel fixings come through carbon tubes.
▲
⟩⟩
jbkiwi
EdW
cenbeth
|
|
💬 Re: Mark me out of 10
1 year ago by 🇬🇧 steve-d (
Warrant Officer)✧ 30 Views · 3 Likes
Flag
Sorry life got in the way so no update. I will try and catch up.
This is the keel. Made a plug out of MDF rings. Spun it up with electric drill and blended its shape with a flap disc in my angle grinder. Made a box to cast silicon in and then with the plug removed I cast the lead. Keel fin is marine ply. Fixings into hull are 2 M6 studs and an 8mm diameter carbon rod. It weighs in at 8.5kg.
▲
⟩⟩
jbkiwi
EdW
cenbeth
|
