    Speranza 01
    by muddy πŸ‡¬πŸ‡§ ( Midshipman)
    πŸ“£










    Click To
    Follow
    5 Posts 17 Comments 28 Photos 27 Likes
    Most recent posts shown first   (Show Oldest First) (Print Booklet)
    πŸ“ Speranza
    28 days ago by muddy ( Midshipman)
    Flag
    View All
    Sanded down the hull, stringers and Transom ready to accept the hull skins, but when opened the wood store the cupboard was near bare, the allocation of ply had been used up, dont ask where, the memory cells are on strike. The combing was added and the propshaft supports, as there are going to be two shafts or twin screw. After these jobs were done i was in limbo and as the frame is rather flexible if not on the point of being flimsey because of the lightness of construction, not my idea. Made a start on the foredeck, with Mahogany planks and a caulking strip, this again was a bit hairaising because of the light framework, but the main hull structure started to be more rigid, here's hoping. There's not a lot more to do because of the materials shortage. More to follow, but not in the near future, not my fault !
    Keep smiling and safe..
    Muddy ..
    πŸ‘ Like
    πŸ’¬ Comments
    πŸ—£οΈ Share
    11
    8
    πŸ’¬ Re: Speranza
    28 days ago by Martin555 ( Admiral)
    Flag
    Hi muddy,
    Looking good so far.
    Shame about the shortage of materials.
    If the lockdown lasts much longer you will end up cutting up the coffee table in to strips LOL!!!

    Martin555.
    πŸ‘ Like
    πŸ’¬ Comment
    πŸ—£οΈ Share
    3
    πŸ’¬ Re: Speranza
    28 days ago by muddy ( Midshipman)
    Flag
    Hello Martin, Thanks for the comment, I was merandering around the outhouse not so long ago "inspecting" an old chair, and there was a loud bellowing " ... your not having that ! " needless to say i did not need further encouragement ! .. lol ..
    Stay safe Muddy..
    πŸ‘ Like
    πŸ’¬ Comment
    πŸ—£οΈ Share
    1
    πŸ’¬ Re: Speranza
    27 days ago by Martin555 ( Admiral)
    Flag
    The words " ... you'r not having that ! " Ring quite loudly in my ears on a regular basis LOL!!!

    Martin555.
    πŸ‘ Like
    πŸ’¬ Comment
    πŸ—£οΈ Share
    1
    πŸ’¬ Re: Speranza
    27 days ago by Ron ( Lieutenant Commander)
    Flag
    Amazing workmanship! Did you pre-drill the holes before putting the deck nails?

    What glue are you using?

    Ron
    πŸ‘ Like
    πŸ’¬ Comment
    πŸ—£οΈ Share
    1
    πŸ’¬ Re: Speranza
    26 days ago by MouldBuilder ( Commander)
    Flag
    Very nice. Good wood working.πŸ‘
    πŸ‘ Like
    πŸ’¬ Comment
    πŸ—£οΈ Share
    1
    πŸ’¬ Re: Speranza
    26 days ago by muddy ( Midshipman)
    Flag
    Hello Ron, A mixture of both realy Ron, where the holes are tight up against the combing they were drilled, and the others a bradaw was used, but the timber was old mahogany and as tough as old boots, easily split. Tend to use Tightbond, the standard stuff although if i,m working on bare wood finish then i use the brown Tightbond think its Tightbond 3. The standard Tightbond is not a waterproof glue , but as nearly ebverything is either painted or varnished i cannot see the point, the Tightbond 3 is a waterproof version as well as being brown in colour..
    The reason for using this glue is that it is an Alphatic, and dries hard so one can work it with sandpaper etc: and it does not have that rubbery texture when dry.
    Hope this helps .. Muddy ..
    πŸ‘ Like
    πŸ’¬ Comment
    πŸ—£οΈ Share
    2
    πŸ’¬ Re: Speranza
    26 days ago by muddy ( Midshipman)
    Flag
    Thank you Sir.. Now i dare not take any close ups ! lol..
    πŸ‘ Like
    πŸ’¬ Comment
    πŸ—£οΈ Share
    1
    πŸ’¬ Re: Speranza
    20 days ago by Dampfgerd ( Master Seaman)
    Flag
    Nice to see that it goes on. We had spoken at the time because I also have the planset, but mine is still sleeping.Now you make me hungry lol
    πŸ‘ Like
    πŸ’¬ Comment
    πŸ—£οΈ Share
    1
    πŸ“ Speranza
    1 month ago by muddy ( Midshipman)
    Flag
    View All
    Only three years ago, i shelved this one, and what with the other's receiving paint i was stuck with nothing to do, a quick look into the started cupboard and there she was, Speranza, first purchased the plans in about 1966-ishhh, and in those days a 40 " boat was big compared to the Aerokits and Veron's, Down to the repair to the spruce stringer which cracked because i did not laminate it, as usual practice, applied a splint trying to close up the gap created by the split and added a strip of Obechi to the outer inbetween the first two formers as this had pulled square instead of being slightly curved, Here's hoping tomorrow i can attack it with a sander.
    Muddy ..
    πŸ‘ Like
    πŸ’¬ Comments
    πŸ—£οΈ Share
    6
    6
    πŸ’¬ Re: Speranza
    1 month ago by RNinMunich ( Fleet Admiral)
    Flag
    Wondered what had happened to 'Speranza' Muddy.
    Seem to remember we were digging around for plans and photos some time ago.
    You've been AWOL since then Warrant!😠
    Think I may need to have a word with your Division Officer; Commander Colin_H!
    As your CO he will decide if disciplinary action is necessaryπŸ€”

    In the meantime carry on Warrant, Steady as you goπŸ‘
    Maybe steaming or soaking the stringers before fitting would have prevented the cracking?
    On the other hand, they were left a rather long time to dry out and 'do their own thing'.
    Happy sanding; don't forget the dust mask!!
    FLEET// 😁
    😎
    πŸ‘ Like
    πŸ’¬ Comment
    πŸ—£οΈ Share
    2
    πŸ’¬ Re: Speranza
    1 month ago by muddy ( Midshipman)
    Flag
    Thank You FLEET, Your comments are always noted.
    My only excuse was Illness, and for that i stand guilty.
    There have been Spasms of enthusiasm, but the ongoing projects were to big, thats why i started the trawler My Susan. Slowly building up to get back into it... !

    It's a long time since i,ve been on the carpet, and not a military one either.
    Will await communication(s) from Colin, ( Who is Colin )..? Besides my regional/Divisional Officer.
    Speranza is back on hold, no timber for the hull, so i,m looking in the cupboard again..
    I never steam or soak strings, i would rather laminate, the usual practice is to rub glue into the timber before applying to the bulkheads etc: this usually works for me, but on this occasion i was trying to rush the job along and chance my luck.. well you can see the resault.
    lol.. The other timber on the frame is well dryed out now as you say, but no other nasties are showing.
    Been adding a few bits to the frame and some filler paint to the Transom, so Sander and Mask tomorrow, here's hoping lol ..
    Regards Muddy.. ( Clicking heels )..
    πŸ‘ Like
    πŸ’¬ Comment
    πŸ—£οΈ Share
    2
    πŸ’¬ Re: Speranza
    1 month ago by RNinMunich ( Fleet Admiral)
    Flag
    Stand easy Warrant!
    Explanation accepted. Trust you are now passed A1 Fit For service πŸ‘
    (Next time get a Chit from the Fleet MOπŸ˜‰)
    See what you mean with the stringers, s'pose you weren't expecting to leave them for so long.
    Not quite sure what you mean with 'laminated stringers' but I guess we live and learn.

    Hope you find what you need in the cupboard.πŸ€“
    Looking forward to the rest of your build.
    Colin_H is a very experienced and expert vintage model boat restorer near Hereford, and Second in Command MB Navy South Western Command. 😊
    Cheers, Doug 😎
    PS: Ich bin Fleet Admiral, nicht Flotten Admiral!!
    Schmerzhaften Fersen-knacken ist nicht unbedingt nΓΆtigπŸ˜‰
    πŸ‘ Like
    πŸ’¬ Comment
    πŸ—£οΈ Share
    1
    πŸ’¬ Re: Speranza
    1 month ago by muddy ( Midshipman)
    Flag
    Thank you Fleet, ( I think ) lol..
    Laminated Stringer, I'll try, if the drawing states 1/4" x 1/4", one would laminate 2 off 1/4" x 1/8", glueing together, thus making up the required size of a 1/4" x 1/4".
    Hope that helps.
    OK about Colin, he has passed me a few "Likes" in the past..

    Not sure abt the P.S. I'll try to decode this later on..

    ATB Doug de Muddy..
    πŸ‘ Like
    πŸ’¬ Comment
    πŸ—£οΈ Share
    1
    πŸ’¬ Re: Speranza
    1 month ago by muddy ( Midshipman)
    Flag
    Doug, I believe this is the translation -

    "PS: I'm Fleet Admiral, not Fleet Admiral !!
    Painful heel cracking is not absolutely necessary"..

    Keep smiling and better still, Keep Safe. atb.. Muddy..
    πŸ‘ Like
    πŸ’¬ Comment
    πŸ—£οΈ Share
    1
    πŸ’¬ Re: Speranza
    1 month ago by RNinMunich ( Fleet Admiral)
    Flag
    Genau Muddy😁
    (Exactly!) Very goodπŸ‘
    No heel clicking please, a simple grovel will suffice WarrantπŸ˜‚πŸ€£
    Good luck with the rest of your build, glad you are recovered and up to it againπŸ‘
    Never heard of laminated stringers before, but it makes sense when such strength is needed.
    Doubles the work thoughπŸ€”
    More power to your sander, keep well.
    Cheers, Doug 😎
    πŸ‘ Like
    πŸ’¬ Comment
    πŸ—£οΈ Share
    1
    πŸ“ Speranza 01
    3 years ago by muddy ( Midshipman)
    Flag
    View All
    Started on the Stringers and Chines, some of the stringers are Spruce, 1/4" x 1/4" , one cracked on the bow curvature, not immediately it was glued and pinned, but about an hour after, should have laminated these spruce stringers as in 1/8" x 1/4" times 2. Another one has cracked since but they are repairable..
    Mixed up a weak solution of PVA and water and painted the rest, hoping this will soften them up and be more pliable. Started on the transom, this is angled with a sharp centre line, but there was a lot of off cuts of Obechie lying around, so it was planked with a curve, first Modelers License applied. A few more dry fits and the bow and transom were assembled up, using stringers as alignment tools, anything will do in these instances even strips of ply. Some of the upper-works combing has been fitted around the transom area. Muddy....

    glue
    chines
    paint
    model
    tools
    pva
    chine
    planked
    bow
    water line
    πŸ‘ Like
    πŸ’¬ Comment
    πŸ—£οΈ Share
    2
    πŸ“ Speranza 02
    3 years ago by muddy ( Midshipman)
    Flag
    View All
    After the marking out, start on the cutting out external lines, then remove the unwanted internal ply, a dry fit or several as progress develops. Regards Muddy....

    wanted
    πŸ‘ Like
    πŸ’¬ Comments
    πŸ—£οΈ Share
    5
    2
    πŸ’¬ Speranza 02
    3 years ago by AlanP ( Lieutenant)
    Flag
    Watching this with interest.πŸ‘

    Alan
    πŸ‘ Like
    πŸ’¬ Comment
    πŸ—£οΈ Share
    2
    πŸ’¬ Speranza 02
    3 years ago by muddy ( Midshipman)
    Flag
    ... 😊 lol .. No pressure then ! .. lol 😊
    I,m afraid this may not be a quick build, because it is an "infill" build.. Always try to have two models on the go, as sometimes waiting for glue or worse still, the paint to dry that's a lot of wood cutting time wasted.. Regards Muddy

    glue
    paint
    model
    wood
    build
    πŸ‘ Like
    πŸ’¬ Comment
    πŸ—£οΈ Share
    2
    πŸ“ Speranza 01
    3 years ago by muddy ( Midshipman)
    Flag
    View All
    This is one that i,ve yearned after for some considerable years. Had the plans in the 1960's, I think, but it was always put on the back burner. But needs must, we have a big sailing lake now and a Sea Queen looks ideal on this water.
    Speranza, built from Plans, first thing source the timber, 5mm ply for keel and bulkheads,and Obechie 6mm X 3mm laminated for stringers and chine lines. Transferring bulkheads/frames to the timber can be daunting, but several methods can be applied. Personally i prefer to Trace the outline and detail then pin prick the outlines onto the timber, you can do this direct from the plan, but using tracing paper or drafting film saves the drawing from disintegrating. Have used carbon paper in the past, but I did find this a bit messy, a personal choice.

    plans
    lake
    sailing
    bulkheads
    bulkhead
    chine
    sea queen
    sail
    frames
    keel
    water line
    built
    πŸ‘ Like
    πŸ’¬ Comments
    πŸ—£οΈ Share
    3
    1
    πŸ’¬ Speranza 01
    2 years ago by Dampfgerd ( Master Seaman)
    Flag
    .

    model
    build
    πŸ‘ Like
    πŸ’¬ Comment
    πŸ—£οΈ Share
