Fly sky FS T4b
10 Posts · 5 Followers · 2 Photos · 13 Likes
Began 3 years ago by
Captain
United KingdomFollow This Thread
Not currently following
> Click to follow
> Click to follow
Latest Post 3 years ago by
( Newest Posts Shown First )
📝 Fly sky FS T4b
40 Views · 2 Likes
Country: 🇬🇧 United Kingdom
Online: 5 hours ago
Online: 5 hours ago
Have Cracked it was caused by a duff receiver tried another and all ok Phew thanks for all the help though
▲
⟩⟩
Colin H
dave976
Stephen james tucker
Warrant Officer📝 Fly sky FS T4b
39 Views · 1 Like
Country: 🇬🇧 United Kingdom
Online: 1 hour ago
Online: 1 hour ago
I agree with Dave 967
What receiver are you using I think the only ones you can use areGR3E, GR3F, R6B,R6C and R9B that have the same protocol as the transmitter?
If you plug the Bind Plug into the battery socket and a 6 volt battery into channel 3 does the red light come on and flash with the transmitter turned off. If it doesn’t
that would point to a receiver problem.
What receiver are you using I think the only ones you can use areGR3E, GR3F, R6B,R6C and R9B that have the same protocol as the transmitter?
If you plug the Bind Plug into the battery socket and a 6 volt battery into channel 3 does the red light come on and flash with the transmitter turned off. If it doesn’t
that would point to a receiver problem.
▲
⟩⟩
Colin H
📝 Fly sky FS T4b
61 Views · 2 Likes
Country: 🇬🇧 United Kingdom
Online: 2 years ago
Online: 2 years ago
Hi Stephen
Are you able to post some pics of both your Tx and Rx ( showing the type and pin connections)? I ask as it is possible your particular Tx and Rx are not compatible or possibly, faulty. If this was a recent purchase I would go back to the retailer for their advice.
As a matter of interest have the Tx and Rx worked and bound with other models?
dave976
Are you able to post some pics of both your Tx and Rx ( showing the type and pin connections)? I ask as it is possible your particular Tx and Rx are not compatible or possibly, faulty. If this was a recent purchase I would go back to the retailer for their advice.
As a matter of interest have the Tx and Rx worked and bound with other models?
dave976
▲
⟩⟩
Colin H
Doogle
📝 Fly sky FS T4b
49 Views
Country: 🇬🇧 United Kingdom
Online: 5 hours ago
Online: 5 hours ago
I have done all that and still it will not bind
▲
⟩⟩
No likes yet
This member will receive 1 point
for every like received
This member will receive 1 point
for every like received
Stephen james tucker
📝 Fly sky FS T4b
69 Views · 1 Like
Country: 🇬🇧 United Kingdom
Online: 2 years ago
Online: 2 years ago
Hi Stephen
There is a manual on line for this Tx. (see pdf file attached)
Page 8 explains the process. Basically you use the binding plug in the battery slot of the rx and a rx battery in any of the other slots on the rx. The red led should be flashing on the rx (it's in bind mode). Press and HOLD the bind button on the TX and switch on. The red Led on the Rx should go solid (binding complete). Release the bind button on the tx. Remove the binding plug from the rx and reconnect the battery to the battery slot on the rx. If the Tx is switched on the rx red Led should be solid (bound to Tx). Connect a servo to each channel and check that all the controls work. If not disconnect and switch off. Repeat the above binding process.
dave976
There is a manual on line for this Tx. (see pdf file attached)
Page 8 explains the process. Basically you use the binding plug in the battery slot of the rx and a rx battery in any of the other slots on the rx. The red led should be flashing on the rx (it's in bind mode). Press and HOLD the bind button on the TX and switch on. The red Led on the Rx should go solid (binding complete). Release the bind button on the tx. Remove the binding plug from the rx and reconnect the battery to the battery slot on the rx. If the Tx is switched on the rx red Led should be solid (bound to Tx). Connect a servo to each channel and check that all the controls work. If not disconnect and switch off. Repeat the above binding process.
dave976
▲
⟩⟩
Colin H
Commodore📝 Fly sky FS T4b
62 Views · 2 Likes
Country: 🇺🇸 United States
Online: 1 day ago
Online: 1 day ago
As RogerA1 said... on most 2.4 ghz systems, the transmitter can over power the receiver if set too close. Move your transmitter at least six feet away from your receiver and try to bind.
▲
⟩⟩
Colin H
RogerA1
Commander📝 Fly sky FS T4b
61 Views · 1 Like
Country: 🇬🇧 United Kingdom
Online: 3 months ago
Online: 3 months ago
try looking at this its a full report on flysky tx rx
▲
⟩⟩
Colin H
📝 Fly sky FS T4b
65 Views · 2 Likes
Country: 🇬🇧 United Kingdom
Online: 1 hour ago
Online: 1 hour ago
Just found the same link. Looks like the guy in the video not 100% at first.
Have you tried moving the transmitter a few feet away from the receiver. On Spektrum if they are too close sometimes it won’t bind.
Have you tried moving the transmitter a few feet away from the receiver. On Spektrum if they are too close sometimes it won’t bind.
▲
⟩⟩
Colin H
ToraDog
Admiral📝 Fly sky FS T4b
92 Views · 1 Like
Country: 🇬🇧 United Kingdom
Online: 3 hours ago
Online: 3 hours ago
Assuming you mean binding transmitter to receiver? Can you tell exactly what transmitter and more important what receiver you have and how your receiver is powered
Have you followed this information on this link
Have you followed this information on this link
▲
⟩⟩
Colin H
📝 Fly sky FS T4b
79 Views · 1 Like
Country: 🇬🇧 United Kingdom
Online: 5 hours ago
Online: 5 hours ago
Having trouble lining these up just will not bind any ideas
▲
⟩⟩
dave976
Stephen james tucker
