'Fairacre', Broads Cruiser
20 Photos · 22 Likes · 15 Comments
7 years ago by 🇳🇿 jbkiwi
Fairacre plan built (MM709, early 70s) Rescued from rubbish bin on farm, rebuilt hull and f/glassed. restored, varnished and re 'glazed' cabin and added grab rails, mast , lights, curtains (leftovers from a Graupner Commodore I built in the 70s) cleats and boarding platform. Restored the deck and varnished. Fitted new prop shaft and rudder and made name decals. cleaned and painted hull interior. (Motor: Graupner 400 monoperm) (ESC: China) (5/10) Plan appears to be modeled on an early UK Bates Starcraft cruiser.
▲
⟩⟩
EdW
Madwelshman
zooma
MartinH2
Peejay
stevedownunder
RNinMunich
boatmam
CB90
DWBrinkman
Len1
hermank
Wolle
flaxbybuck
jumpugly
AlessandroSPQR
Martin555
sgtbarnes
doghouse
Donnieboy
figtree7nts
Inkoust
|
💬 Re: 'Fairacre', Broads Cruiser
2 hours ago by 🇬🇧 zooma (
 Rear Admiral)✧ 5 Views · 1 Like
Flag
Thanks JB - I will give that a try.
Bob. ▲
⟩⟩
hermank
|
|
Login To
Remove Ads 💬 Re: 'Fairacre', Broads Cruiser
2 hours ago by 🇳🇿 jbkiwi (
 Fleet Admiral)✧ 6 Views · 3 Likes
Flag
Hi Bob,
from memory I used either meths or isopropyl alcohol, then detergent then hosed it out and let it dry for a few weeks. I know i had to be a bit 'severe' with it, but the hull needed a major rebuild, and f/glassing, so I wasn't too worried. If you use Zinsser stain blocker undercoat, it will cover what remains no problem. You can then overcoat it with an enamel. JB ▲
⟩⟩
hermank
Madwelshman
zooma
|
|
💬 Re: 'Fairacre', Broads Cruiser
4 hours ago by 🇬🇧 zooma (
Rear Admiral)✧ 7 Views · 1 Like
Flag
Hi JB,
It looks like your Fairacre was previously powered by an IC engine and so you had an oil soaked hull to clean up. The interior certainly looks nice and clean now, so I was wondering what method you used to clean the oil soaked wood? I have a restoration model with really oily hull and I need to find the best way of cleaning the wood so that I can make some repairs that will need the PVA glue to be able to penetrate the wood fibres. Bob. ▲
⟩⟩
hermank
|
|
💬 Re: 'Fairacre', Broads Cruiser
4 hours ago by 🇬🇧 zooma (
Rear Admiral)✧ 7 Views · 2 Likes
Flag
You have made a really nice restoration JB.
Another Classic Model Power Boat has been saved, and she looks beautiful - well done 👍 Bob. ▲
⟩⟩
hermank
jbkiwi
|
|
💬 Re: 'Fairacre', Broads Cruiser
2 years ago by 🇮🇹 AlessandroSPQR (
Fleet Admiral)✧ 27 Views · 2 Likes
Flag
Thanks so much Jbkiwi.
▲
⟩⟩
hermank
Len1
|
|
💬 Re: 'Fairacre', Broads Cruiser
2 years ago by 🇳🇿 jbkiwi (
Fleet Admiral)✧ 41 Views · 3 Likes
Flag
Hi Hermank, this will make you feel even older😂
JB
▲
⟩⟩
EdW
Len1
hermank
|
|
💬 Re: 'Fairacre', Broads Cruiser
2 years ago by 🇳🇿 jbkiwi (
Fleet Admiral)✧ 41 Views · 3 Likes
Flag
Hi Alessandro
re Can I insert the data of this RC model of yours in the list of the first message of this topic? please feel free to do what you like with it.👍 JB ▲
⟩⟩
hermank
Len1
AlessandroSPQR
|
|
💬 Re: 'Fairacre', Broads Cruiser
2 years ago by 🇺🇸 DWBrinkman (
 Commodore)✧ 41 Views · 4 Likes
Flag
Amazing restoration! The before and after pictures tell quite a story. Brilliant work.
▲
⟩⟩
hermank
Len1
jbkiwi
AlessandroSPQR
|
|
💬 Re: 'Fairacre', Broads Cruiser
2 years ago by 🇮🇹 AlessandroSPQR (
Fleet Admiral)✧ 36 Views · 2 Likes
Flag
Hi John, thanks for your reply.
Can I insert the data of this RC model of yours in the list of the first message of this topic? ▲
⟩⟩
hermank
Len1
|
|
💬 Re: 'Fairacre', Broads Cruiser
2 years ago by 🇧🇪 hermank (
Rear Admiral)✧ 39 Views · 3 Likes
Flag
JBKIWI
what do you do to me!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!! i feel very very old now. The commodore was the second boat i made after Graupner's constellation which is now over 55 years ago😋😋😋😋 ▲
⟩⟩
jbkiwi
Len1
AlessandroSPQR
|
|
💬 Re: 'Fairacre', Broads Cruiser
2 years ago by 🇳🇿 jbkiwi (
Fleet Admiral)✧ 45 Views · 4 Likes
Flag
Hi Alessandro
Re dimensions the length is 770mm width average 180mm (tapers from bow) weight is 1.75kg (with 2s 2200mah LiPo) prop is a 70s Graupner 2 blade 40mm diam (pitch unknown but moderate) JB
▲
⟩⟩
Peejay
AlessandroSPQR
Len1
hermank
|
|
Login To
Remove Ads 💬 Re: 'Fairacre', Broads Cruiser
2 years ago by 🇳🇿 jbkiwi (
Fleet Admiral)✧ 45 Views · 4 Likes
Flag
Hi FB, thanks for the comment curtains are actually left over material from a Graupner Commodore kit I built in the late 70s (as mentioned). Knew it would come in handy one day. I found out that the actual 100% boat (Fairacre) the model plans were drawn from, was a Bates 'Starcraft' (not a 'broads cruiser' as I was originally told it was). A number were used as hire launches,- now a fair few restored and collectable. There is also a Starcraft owners site on the web.
JB
▲
⟩⟩
flaxbybuck
Peejay
AlessandroSPQR
Len1
|
|
💬 Re: 'Fairacre', Broads Cruiser
2 years ago by 🇬🇧 flaxbybuck (
 Captain)✧ 36 Views · 3 Likes
Flag
Congratulations on a great restoration JB. She looks beautiful, and a boat for which you can feel rightly proud. And I do like the curtains; they seem so fitting and of the period. Sometimes it is the small details that really set off a boat. 😉😉
▲
⟩⟩
AlessandroSPQR
Len1
jbkiwi
|
|
💬 Re: 'Fairacre', Broads Cruiser
2 years ago by 🇺🇸 jumpugly (
 Admiral)✧ 43 Views · 3 Likes
Flag
Rescues and rebuilds are their own rewards. Great lines on this one JB!
▲
⟩⟩
AlessandroSPQR
Len1
jbkiwi
|
|
💬 Re: 'Fairacre', Broads Cruiser
2 years ago by 🇮🇹 AlessandroSPQR (
Fleet Admiral)✧ 40 Views · 3 Likes
Flag
Hi jbkiwi.
Excellent recovery and restoration. Could you tell me the length of the model and the diameter of the propeller? If you also know the weight. ▲
⟩⟩
