    34" Vosper RAF Crash Rescue Tender - Aerokits model
    by Back in the Groove πŸ‡¬πŸ‡§ ( Leading Seaman)
    πŸ“£










    Click To
    Follow
    2 Posts 27 Comments 0 Photos 9 Likes
    Most recent posts shown first   (Show Oldest First) (Print Booklet)
    πŸ“ Float Test!
    26 days ago by Back in the Groove ( Leading Seaman)
    Flag
    View All
    So having stripped out all the old equipment - see image of home made rudder servo! - I decided to check for leaks. I used some soup cans for ballast, and after around 45 mins found some water coming up the old 3/16" x 9" prop shaft.
    Having asked advice on the forum, I need a new 5mm prop shaft, but will wait until I have the motor, before ordering one. I may need a different length, and now I know I'm opening the hull, I may as well fit a new metric rudder and tube too πŸ€”

    5mm prop shaft
    πŸ‘ Like
    πŸ’¬ Comments
    πŸ—£οΈ Share
    2
    1
    πŸ’¬ Re: Float Test!
    26 days ago by Martin555 ( Rear Admiral)
    Flag
    Hi,
    I like that old servo system, using that system slightly modified you could control all sorts of things.

    Martin555.
    πŸ‘ Like
    πŸ’¬ Comment
    πŸ—£οΈ Share
    2
    πŸ“ 34" Vosper RAF Crash Rescue Tender - Aerokits model
    30 days ago by Back in the Groove ( Leading Seaman)
    Flag
    View All
    It must have been in the early '70's when my father and brothers built this model. It had a car blower motor, a home made server to steer (see picture), and my eldest brother built the RC system. We had fun on many boating lakes on holidays in North Wales, and I've decided to refurbish her, and get her on the water again. She was named "Endeavour", as my mother said it took a lot of endeavour to build her! I think I'm going to fit the missing chine and gunwale stringers and repaint her as a Fireboat - of some sorts!
    I'd like to go modern with the RC, motor (brushless?) and metal geared servo.
    Any advice - particularly on motor sizing would be appreciated. I saw a similar Fireboat on the water at Southport Model Boat Club open day recently, with an 850 motor, which seemed to sail very nicely

    Fireboat
    πŸ‘ Like
    πŸ’¬ Comments
    πŸ—£οΈ Share
    7
    25
    πŸ’¬ Re: 34" Vosper RAF Crash Rescue Tender - Aerokits model
    30 days ago by Martin555 ( Rear Admiral)
    Flag
    Hi,
    You have a lot of work ahead of you but it will be nice to see the old boat have a new life.
    Good luck.

    Martin555.

    boat
    πŸ‘ Like
    πŸ’¬ Comment
    πŸ—£οΈ Share
    1
    πŸ’¬ Re: 34" Vosper RAF Crash Rescue Tender - Aerokits model
    30 days ago by mturpin013 ( Lieutenant)
    Flag
    welcome to the site
    there have been some recent crash tender builds in the blogs section. One is mine (not yet complete) and Robs which is on the water, I think you'll find all you need on this site.
    The Vosper 46” RAF Crash Tender Kit By Vintage Model Works
    by mturpin013 πŸ‡¬πŸ‡§ ( Lieutenant)
    and
    Vintage Model Works 46" RAF Crash Tender
    by robbob πŸ‡¬πŸ‡§ ( Captain)
    PS there are many others of the 36" version
    πŸ‘ Like
    πŸ’¬ Comment
    πŸ—£οΈ Share
    3
    πŸ’¬ Re: 34" Vosper RAF Crash Rescue Tender - Aerokits model
    29 days ago by Graham93 ( Chief Petty Officer 1st Class)
    Flag
    Hi,

    Welcome on board. I’ Currently refurbishing a 34” Crash Tender that I built about the same time as yours.

    I have fitted mine with a Turnigy brushless D3536/6 1250kV motor running on a 3S LiPo battery and performance is great. You will need to fit the missing stringers though

    Graham93

    LiPo
    πŸ‘ Like
    πŸ’¬ Comment
    πŸ—£οΈ Share
    2
    πŸ’¬ Re: 34" Vosper RAF Crash Rescue Tender - Aerokits model
    29 days ago by Rookysailor ( Lieutenant)
    Flag
    Looks like it could be an old Aerokits Fireboat, depends on the size of the boat, what size motor to put in, the one you saw at Southport, with a 850 brushed motor, would probably be a 1/12 scale, but
    you can also ket the smaller 1/16 scale.😐

    Cheers, Peter

    Aerokits Fireboat
    boat
    πŸ‘ Like
    πŸ’¬ Comment
    πŸ—£οΈ Share
    2
    πŸ’¬ Re: 34" Vosper RAF Crash Rescue Tender - Aerokits model
    29 days ago by Back in the Groove ( Leading Seaman)
    Flag
    Thank you. I've started to look at other blogs, to help me decide how far to go with this one. I'm hoping to do the refurb over the winter, and install the new motor/servo and electronics, then remove, so I can do a better job on the inside, before doing the repair and repaint
    πŸ‘ Like
    πŸ’¬ Comment
    πŸ—£οΈ Share
    2
    πŸ’¬ Re: 34" Vosper RAF Crash Rescue Tender - Aerokits model
    29 days ago by Back in the Groove ( Leading Seaman)
    Flag
    Thanks Graham93, I saw your picturesπŸ˜€ - How did you decide what size motor to use? I do intend to fit the missing stringers. I can't remember why they weren't fitted - it's a good while ago now πŸ˜†
    πŸ‘ Like
    πŸ’¬ Comment
    πŸ—£οΈ Share
    1
    πŸ’¬ Re: 34" Vosper RAF Crash Rescue Tender - Aerokits model
    29 days ago by Back in the Groove ( Leading Seaman)
    Flag
    Yes Peter, It's an Aerokits model - I still have the original intructions - distributor was KeilKraft. Scale drawing says 3/4" to 1'. Original boat was 46ft. I think that must be 1/16 scale? Model is 34 and a bit inches long

    Aerokits
    boat
    πŸ‘ Like
    πŸ’¬ Comment
    πŸ—£οΈ Share
    1
    πŸ’¬ Re: 34" Vosper RAF Crash Rescue Tender - Aerokits model
    29 days ago by Martin555 ( Rear Admiral)
    Flag
    "How did you decide what size motor to use?"
    Now that is a very good question.
    I too would know how to chose the right motors for boats.
    Obviously it depends on the type of boat that you want them for.
    Maybe it is a case of trial and error or is there a formula ?

    Martin555.
    πŸ‘ Like
    πŸ’¬ Comment
    πŸ—£οΈ Share
    1
    πŸ’¬ Re: 34" Vosper RAF Crash Rescue Tender - Aerokits model
    29 days ago by Martin555 ( Rear Admiral)
    Flag
    I have looked at some other posts and found this By dbninja.
    His boat is a 34" Crash Tender.

    Power Is Graupner speed 600 8.4v on a 9.6v nimh pack, prop Is 40mm 2blade.

    Hope this helps.

    Martin555.

    boat
    πŸ‘ Like
    πŸ’¬ Comment
    πŸ—£οΈ Share
    1
    πŸ’¬ Re: 34" Vosper RAF Crash Rescue Tender - Aerokits model
    29 days ago by Back in the Groove ( Leading Seaman)
    Flag
    Hi Martin555,
    Many Thanks for this - I'd not seen that post. I've actually written to Graupner and Mtroniks today to ask for a recommendation, so will see what I get back. It does seem to be a dark art for the inexperienced though!
    πŸ‘ Like
    πŸ’¬ Comment
    πŸ—£οΈ Share
    1
    πŸ’¬ Re: 34" Vosper RAF Crash Rescue Tender - Aerokits model
    29 days ago by Martin555 ( Rear Admiral)
    Flag
    That will be interesting to see what you get back from Graupner and Mtroniks.
    I have made many many model boats and there seemed to be only two ways to fined out what motor for what boat, and that was to experiment or know someone who has already made the boat that you want to make.
    Now with the internet and the good members of this site it is much easer.

    Martin555.
    πŸ‘ Like
    πŸ’¬ Comment
    πŸ—£οΈ Share
    1
    πŸ’¬ Re: 34" Vosper RAF Crash Rescue Tender - Aerokits model
    29 days ago by Graham93 ( Chief Petty Officer 1st Class)
    Flag
    I did some searching on the web and found some info on brushless motor sizes and suggestions based on the length of the hull. Needless to say, I can't find it again when I searched today so that I could let you have the linkπŸ€” It was 4-5 months ago.

    I don't know if there are better options, there probably are. I've been lucky as the motor I bought works fine, so I haven't had the expense of having to try a different one.

    Graham93
    πŸ‘ Like
    πŸ’¬ Comment
    πŸ—£οΈ Share
    2
    πŸ’¬ Re: 34" Vosper RAF Crash Rescue Tender - Aerokits model
    28 days ago by Elsrickle ( Chief Petty Officer 2nd Class)
    Flag
    I did a refurbish on one I got on eBay
    Fitted 2 brushless HPD 2920-4000 with 60a hawk esc’s running with 30 mm 3blade props also fitted rubber gaiters on top of rudder shafts as they were very close to the water line and I kept getting water seepage in the stern
    πŸ‘ Like
    πŸ’¬ Comment
    πŸ—£οΈ Share
    1
    πŸ’¬ Re: 34" Vosper RAF Crash Rescue Tender - Aerokits model
    28 days ago by Back in the Groove ( Leading Seaman)
    Flag
    Hi Martin555, Graupner told me to ask a supplier in the UK, or at a Model Boat Club - fair enough, but there are so many different opinions!! - 600 or 850 brushless being the most common. M-troniks recommended their G2 Hydra50, which I quite like the idea of, as they are UK based, and "waterproof". I'll do some comparisons of similar 1400kv motors, but as a beginner, I think it makes sense to use a "matched" system?
    πŸ‘ Like
    πŸ’¬ Comment
    πŸ—£οΈ Share
    2
    πŸ’¬ Re: 34" Vosper RAF Crash Rescue Tender - Aerokits model
    28 days ago by Back in the Groove ( Leading Seaman)
    Flag
    Thanks Elsrickle. I think you may have the 42" 12th scale model? I only have one motor, and yours seem to be very powerful. I'm hoping not to have any leaks, but am now wondering if my rudder and prop tube will be leaky - Maybe I do a test in the bath!!πŸ˜€
    πŸ‘ Like
    πŸ’¬ Comment
    πŸ—£οΈ Share
    1
    πŸ’¬ Re: 34" Vosper RAF Crash Rescue Tender - Aerokits model
    28 days ago by Elsrickle ( Chief Petty Officer 2nd Class)
    Flag
    View All
    Hi the I have is the aero kit firefloat crash Tender 36 inch model
    Change to twin props as this was fitted in real ones

    kit
    πŸ‘ Like
    πŸ’¬ Comment
    πŸ—£οΈ Share
    2
    πŸ’¬ Re: 34" Vosper RAF Crash Rescue Tender - Aerokits model
    28 days ago by Back in the Groove ( Leading Seaman)
    Flag
    Hi, I think found a post from you around a year ago re a 46” Vosper model, where you said your boat was β€˜a bit fast at 11v’. Is your boat noisy relative to others?

    boat
    model
    πŸ‘ Like
    πŸ’¬ Comment
    πŸ—£οΈ Share
    1
    πŸ’¬ Re: 34" Vosper RAF Crash Rescue Tender - Aerokits model
    27 days ago by Rookysailor ( Lieutenant)
    Flag
    The 1/12 scale model was 46" in length not 42", as the real boat was 46ft, 1/12 equals 1" to the foot.😐


    Cheers, Peter
    πŸ‘ Like
    πŸ’¬ Comment
    πŸ—£οΈ Share
    2
    πŸ’¬ Re: 34" Vosper RAF Crash Rescue Tender - Aerokits model
    27 days ago by Elsrickle ( Chief Petty Officer 2nd Class)
    Flag
    Hi it could have been tried it first on 11volt very fast and very unstable when you gave it full throttle. That’s the reason am on 7 volt lipos
    πŸ‘ Like
    πŸ’¬ Comment
    πŸ—£οΈ Share
    2
    πŸ’¬ Re: 34" Vosper RAF Crash Rescue Tender - Aerokits model
    27 days ago by RNinMunich ( Fleet Admiral)
    Flag
    Agreed Sub.
    There were actually ten versions of the Fire Float (seemingly often erroneously called a 'Crash Tender') ranging from 37.5' to 60'.
    http://www.rafboats.co.uk/ff46vmk2.html
    Most popular version (don't know why!) seems to be the 46' version of which only two examples were ever built and which never saw the exciting and heroic service of their predecessors.
    Each to his own I suppose!
    😎
    http://www.rafboats.co.uk/ff46vmk2.html
    πŸ”—

    version
    πŸ‘ Like
    πŸ’¬ Comment
    πŸ—£οΈ Share
    2
    πŸ’¬ Re: 34" Vosper RAF Crash Rescue Tender - Aerokits model
    27 days ago by redpmg ( Sub-Lieutenant)
    Flag
    Whoops - engage mind before opening mouth ........
    Thought you were talking about models of which there must have been thousands of versions built including commercial toy types - a scratch built 6' one I saw running in the sea - looking just like the real one - powered by a 25cc 2 stroke motor. But the Fireboats everyone thinks of are 93 & 94 . Strange the fascination with those when they were the only two ever built..............

    models
    πŸ‘ Like
    πŸ’¬ Comment
    πŸ—£οΈ Share
    1
    πŸ’¬ Re: 34" Vosper RAF Crash Rescue Tender - Aerokits model
    27 days ago by Back in the Groove ( Leading Seaman)
    Flag
    Thanks Elsrickle - really helpful to understand all factors affecting performance

    Bill
    πŸ‘ Like
    πŸ’¬ Comment
    πŸ—£οΈ Share
    1
    πŸ’¬ Re: 34" Vosper RAF Crash Rescue Tender - Aerokits model
    27 days ago by redpmg ( Sub-Lieutenant)
    Flag
    Looks like there were only 4 actual designs Doug - 3 specific fireboat types/prototypes - the other 7 based on seaplane tenders - obviously with appropriate water cannon fitted - most of us have never heard of the 55' and 60' versions before - and we are interested modellers.
    πŸ‘ Like
    πŸ’¬ Comment
    πŸ—£οΈ Share
    1
    πŸ’¬ Re: 34" Vosper RAF Crash Rescue Tender - Aerokits model
    26 days ago by Graham93 ( Chief Petty Officer 1st Class)
    Flag
    View All
    Re: There were actually ten versions of the Fire Float (seemingly often erroneously called a 'Crash Tender')

    Rightly or wrongly, referring to these as 'Crash Tenders' probably has something to do with this!

    Graham93
    πŸ‘ Like
    πŸ’¬ Comment
    πŸ—£οΈ Share
    2
    πŸ’¬ Re: 34" Vosper RAF Crash Rescue Tender - Aerokits model
    26 days ago by Back in the Groove ( Leading Seaman)
    Flag
    Graham93,
    That plan looks exactly like the one I have - only mine is much more yellow! I have 2 other documents - the Building Instructions and "Constructional Details"
    πŸ‘ Like
    πŸ’¬ Comment
    πŸ—£οΈ Share
    1
