Members might like to view my experimental solar powered "BOAT " More like an aircraft carrier !! No batteries carried even for the radio. Brushless motor running from 24 cells giving 12volts. Slightest shadow will stop it.The panel i made myself by buying individual solar cells from Ebay and soldering them up.The cells are sandwiched between glass which makes it quite heavy and next project will have no glass but the cells are VERY fragile.

British Power Boat 64 ft RNZAF HSL scratch built 36" R/C model with twin systems including sound. Brushless 2000kv w/cooled (pump) in-runners, 30A car ESCs, 2200mah 2s LiPos remote lights etc. Started off in 1940, new with the RNZAF and had many modifications over the years till decommissioned, including machinery reduced to twin 671 Greymarine GMs (from the original 3x 500hp Napier Sea Lions) which were finally removed around 7yrs ago and replaced with a single 650hp GM Detroit 8v92T1 (still does 20 knots in its latest configuration ! - see this on the photo gallery of this model) This boat is in far better condition than the ex Phil Clabburn restoration of HSL 102 (he didn't have much to start with) and the hull has never had any major rebuild apart from being glassed to the W/L. Even today there is no way most people would pick it for 80yrs old. Those hulls never age! (ie some of the beautiful 'Whale Back' conversions still around)

Hi chaps here are a few photos of the of my Wave Princess. Never built a boat before but, she looked so lonely and abandoned l just had to do something with her. picked up the partly built hull and box of bits from Avicraft in bromley it was among a collection of old model aeroplanes l think the original builder now sails with St peter. The aft cabin was completely crushed down and somebody had given it a coat of brown stain. Not very appealing. still always been a silly sod for a pretty girl.

Boat is Scratch built 36" British Power Boat 64ft High Speed ASR Launch which belonged to the RNZAF. The launch was one of the 22 built and was shipped to NZ in 1940. it was the only one of its type in the Southern Hemisphere. Model has twin motors, ESCs, sound units etc. Has remotely switched water pump for water cooled brushless 2000kv in runner motors and remotely switched lighting. Uses 2x 2200mah 2s LiPos for drive and 1 1800mah LiPo for the pump (also a separate battery for the LED lights. Boat is built with strip planked balsa on ply frame and fiber glassed. Deck is ply, wheelhouse is varnished balsa. The colour is as it was for most of its time in the RNZAF . Took about 5 years on and off to build and finished it last year. (please ignore the time date - can't get rid of it .

Built plank on frame and then glassed on outside and resin on inside. it is based on the time it was charted to Australia to take supplys to Antarctic stations. it is electric drive on 2/5 to 1 reduction . it is built on 1/48 scale

This is my scratch built 36" RNZAF British Power Boat 64' HSL (arrived in NZ 1940). I actually went on board this vessel in 1968 when it was still in original form (the RNZAF having disposed of it in the 50s) This vessel is still around and has been recently re modelled (2nd time since early 70s) and I was lucky last year to have met the present owner and go on board (2nd time in 49yrs!)and take a few photos. The vessel was modified a number of times by the RNZAF over the years (air intakes, removal of the fore deck machine guns, wheelhouse turret etc so I sort of went in the middle. I found a few drawings of the type in an old mag which had side and top views plus the bulkheads and their positions, so I took them along to a copying shop and kept enlarging them until I had the desired proportions. This worked out quite well and using a few methods from other models I had built, managed to frame (ply) the hull and then fully strip plank it in balsa. it was then fiber glassed. The deck is ply, lined and varnish stained. The wheelhouse is varnished balsa with the top removable for access. The wheelhouse interior has detail such as controls, instrument panels, skipper, steps to wardroom etc but is not too detailed as it is not seen. The boat has full lighting by remote switch, lights are all LED.
The propulsion side has dual everything (motors, ESCs, sound units), would have had 3x but ran out of space! Motors are 28mm 2200Kv water jacketed in-runners (cooled by remotely switched pump) using 30A Chinese ESCs (have 5A BEC, Fwd and Rev). Twin sound units are 'GT Power' car units which have around 40 different sound selections, from Cosworths to diesels and are computer programmable (as well as manually on the unit ) for various functions. I am using one of the v8 sounds (8 cyls short in my application) which I think is as near as you are going to get to 3 Napier Sea Lions (for which there is obviously no sound available) They 'start' 'Idle' and are fully proportional in fwd and rev and can sound quite realistic (will attempt to put up a vid later).
Batteries are 2x 2200mah 2s 20c LiPos which will last around 2hrs at least of sailing (they also run the sound units) Still have a few small things left to do (have just made wheelhouse air intakes) but don't want to get too fiddly. Just want to keep it a practical model.

This is a restoration of a launch I was given that was found in a rubbish bin on a farm here in Auckland it is an old RCM ? plan built 'Fairacre' and was pretty rotten when I received it as it is made in balsa and had been wet for quite a while. I stripped it down, re 'planked' large portions of the hull and fiber glassed it, re- built the cabin, re- marked the deck planks, fitted lights, curtains (ex Graupner Commodore bits from the 70s I had kept), stern ladder, cleats etc. it is fitted with a 540 brushed motor (originally had an old Graupner monoperm) and 70s Graupner ESC and Using 2.4 Radio gear. I still have a few things I'd like to do such as a re-wire, fitting chine spray rails, better motor and maybe some safety rails, but for now it does the job.

Sea trials of my 1/15 scale model of a Freeman 32 Mk1 river cruiser

1/15 scale scratch built model of my boat (Freeman 32 Mk1) Rhapsody.

My dad built this over a long period of time, starting in the '80s. The hull is fibreglass and the rest is scratch built from plastic card, balsa, ply, wire and anything else he could adapt.
Although he installed the motors, props and rudders he never completed the RC installation or tested it. I inherited his boat models a few years ago and wanted to "finish the job", getting the model on the water. After installing the RC gear and batteries over the last few months, this weekend was the first sailing outside the bath at the Valley Gardens boating lake.
Happy to report that it sailed really nicely, seems to be reasonably stable although I did restrict it to calmer times when the MTBs and faster boats weren't running !
HMS Cadiz was a battle class destroyer, laid down and launched during WW2 although she didn't receive her commission until 1946 so didn't see combat with the Royal Navy, serving with the home fleet. Due to the changeover in pennant numbering she was originally allocated R09 and later, when the admiralty decided to revert to the D for Destroyer pennant numbering she was assigned D79. To reflect this my model has D79 on the starboard side and R09 on the port side.
She was sold to Pakistan in the late '50s, and renamed PNS Khaibar. She was sunk with the loss of nearly all hands in 1971 in the indo-Pakistan war.

Huson 24 RC sailboat wooden hull. I have a small fleet of these. They are extremely stable in high wind. Bought this one online in pretty good condition.
Did a lot of smoothing on the epoxy coated hull. I use West Systems epoxy because it flows so well - like paint - and doesn’t stink.

A Little bit forward
It is a long way untill its ready

I built this from scrap wood i had lying around i bought the tanks from china the motor is a 850 mfa with a speed controller powered by a 11.1v 5000 mah battery
still in progress 😉

When I was in high school back in 1957 I built a kit of the Comet Gypsy Sloop Jr. in 2016 I found the drawings on-line for the Gypsy Jr. The boat was entered in woodworking class at our county fair where it received a blue ribbon. it has a working wheel that turns the rudder. Now I have under construction a 32 inch version that I would like to radio control. I'm not too sure how to set up or what type of servo to install.

Test run on compressed air of "IMARA's" tug steam plant.
