Sea Hornet
While waiting for a second coat of epoxy to dry on my other model i enlarged some plans of an old Sea Hornet kit that I purchased a few days ago. I copied them 25% larger which gives length of 32 inches i then cut out the keel and bulkheads, i have only fitted them loosely for the picture.
Done a bit more to the hull and fitted the stringers and the bottom skins
Done a bit more to the hull and fitted the stringers and the bottom skins
Liked by Madwelshman and canabus and
I will be watching this built very close, as I have built one from original plans and also did the 25% as a future project.
Because of the very limited engine and radio hatch, I design them larger, but, you are on the right path. I installed a 28mm brushless motor, 3S 2650mah Lipo battery with a 2 blade 32mm brass prop. I don't think the 25% bigger a one would require any more power as it a rocket. My hatches run down the deck planking lines, the original hatches are only for show.
The engine starts from the front seat and finishes at the rear windscreen.
I made up the cockpit floors etc. before I skinned the sides, a lot easier, also the floor is split over the keel with the seats one piece.
